110V UPS 1-3K Single Phase High Frequency Short Circuit Protection Online UPS Power Supply
Inquire NowDescription
Introducing the 110V UPS 1-3K Single Phase High Frequency Online UPS Power Supply, designed to deliver high reliability and performance in critical power situations. This advanced UPS model utilizes online double conversion technology, ensuring a stable power supply for sensitive electronic devices. With a wide input voltage range, it can adapt seamlessly to various environments, making it an ideal choice for data centers, commercial facilities, telecom systems, and IT rooms.
Choose between tower and rackmount configurations to suit your installation needs. The UPS features an RS232 communication port and optional USB/SNMP adapter for enhanced connectivity. For those requiring additional power, external battery cabinet kits are available, further extending the UPS’s capacity and runtime.
Whether you’re safeguarding essential data or powering critical systems, this UPS offers peace of mind with its robust design and exceptional performance.
Specifications
| Model | AW1KS/L | AW2KS/L | AW3KS/L | RAW1KS/L | RAW2KS/L | RAW3KS/L | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Capacity | 1000 VA | 2000 VA | 3000 VA | 1000 VA | 2000 VA | 3000 VA | |||||
| Box Structure | Tower type | Rackmount type | |||||||||
| Rated Voltage | 110/115/120/127 Vac | ||||||||||
| Phase | Single phase | ||||||||||
| Frequency | 40-70 HZ | ||||||||||
| Power Factor | Full load 0.99 | ||||||||||
| Battery Voltage | 24/36 Vdc | 48/72 Vdc | 72/96 Vdc | 24/36 Vdc | 48/48 Vdc | 48/96 Vdc | |||||
| Battery Quantity | 2*7Ah12V / External | 4*7Ah12V / External | 6*7Ah12V / External | 2*7Ah12V / External | 4*7Ah12V / External | 4*9Ah12V / External | |||||
| Recharge Time | -5 hours (depends on capacity of battery) | -5 hours (depends on capacity of battery) | |||||||||
| Charging Current Max | 1.5A/4A | 1.5A/4A | 1.5A/4A | 1.5A/4A | 1.5A/4A | 1.5A/4A | |||||
| Floating Voltage | 27.3/41.0 Vdc | 54.6/81.8 Vdc | 81.8/109.2 Vdc | 27.3/41.0 Vdc | 54.6/54.6 Vdc | 54.6/109.2 Vdc | |||||
Additional Information
- Application areas include data centers, 19” rack devices, commercial facilities, telecom systems, IT rooms, and precision instruments.
- Optional features include RS232 communication port, USB/SNMP adapter, dry contact, and emergency power off (EPO).
- External battery cabinet kits available for increased capacity.
