11KV Drop-out Fuse Cutout Fuerte design
Inquire NowDescription
Outdoor Expulsion Drop-out Type Distribution Fuse Cutout 11kV is a reliable protection device designed to safeguard power systems from overloads and short-circuit failures. With ratings ranging from 11kV to 36kV, this high-performance cutout meets the stringent standards of IEC 600282-2, ensuring longevity and durability in demanding outdoor environments.
This cutout boasts exceptional over-current protection capabilities alongside high breaking current thresholds, making it a vital component for any electrical distribution system. Its high industrial frequency withstand voltage and mechanical strength are indicative of its robust design, while strict quality testing guarantees reliability and safety in operation.
Specifications
| Attribute | Unit | FSC-1 (100A) | FSC-1 (200A) |
|---|---|---|---|
| Rated Voltage | KV | 11 | 11 |
| Rated Current | A | 100 | 200 |
| Breaking Current | KA | 10 | 12 |
| Impulse Voltage | KV | 110 | 110 |
| Power-frequency withstand voltage | KV | 40 | 40 |
| Leakage distance | mm | 230 | 230 |
| Weight | kg | 7.30 | 7.80 |
| Dimensions | cm | 38.5 x 34.5 x 10.5 | 38.5 x 34.5 x 10.5 |
Additional Information
- Port: Ningbo, Shanghai, Any port in China
- Payment Terms: T/T, L/C
- Packing: 1 pcs per carton lined with foam, packed together on a pallet. Custom packaging available upon request.
- Shipping: Options include sea, air, or express based on customer preference.
- Delivery Time: Dependent on order quantity, typical delivery period is 35 days.
