12 Ton 16 Ton 20 Ton 25 Ton Electric Heavy Forklift Truck Ton

Inquire Now

SOCMA Electric Forklift Features
1,The waterproof grade reaches IP67, which can meet the difficult conditions such as rainy weather and ensure easy cleaning.
2,Low cost of use: the power consumption of electric forklift is only about 30% of traditional internal combustion forklift.
3,The international standard dual charging interface can meet the needs of fast charging and constant current charging; and other variety of charging specifications are optional if necessary.
4,Equipped permanent magnet synchronous motors, combined with a variety of motor coordinated control technologies, can ensure reasonable overload matching and optimized energy management.
5,Zero emission, zero pollution and low noise.
6,Easy inspection and maintenance ,low maintenance cost.
7,As it adopts the design of high-voltage and high power system ,the full-load travel speed, lift speed and gradeability are greatly improved compared with internal combustion forklift trucks.
8,Equipped high capacity and high energy density LFP battery can ensure long-term work for more than 8 hours after being fully charged. The battery can be recharged more than 4000 cycle or used for more than 8 years.


Basic Parameter

Technical Parameter
DISTINGUISHING MARK MANUFACTURER SCOMA SCOMA SCOMA SCOMA
MANUFACTURER’S TYPE DESIGNITION HNF120-EL HNF160-EL HNF200-EL HNF250-EL
DRIVE:ELECTRIC(BATTERY OR MAINS),DIESEL,PETROL,LPG BATTERY BATTERY BATTERY BATTERY
OPERATOR TYPE:HAND,PEDESTRAIN,STANDING,SEATED,ORDER-PICKER SEATED SEATED SEATED SEATED
RATED CAPACITY/LOAD KG 12000 16000 20000 25000
LOAD CENTRE DISTANCE C(MM) 600 900 1250 1250
WHEELBASE Y(MM) 3000 3800 4000 4400
WEIGHTS SERVICE WEIGHT KG 18000 25000 32500 35000
TYRES/CHSSIS TYRES:L=PNEUMATIC,V=SOLID,SE=PNEUMATIC-SHAPED SOLID L L L L
TYRE SIZE,FRONT/REAR 10.00-20-18PR 12.00-24-18PR 14.00-24-28PR 14.00-24-28PR
WHEELS,NUMBER FRONT/REAR(X=DRIVEN WHEELS) 4X/2 4X/2 4X/2 4X/2
TREAD,FRONT,STANDARD/WIDE TREAD b10(MM) 1650 2060 2200 2200
TREAD REAR b11(MM) 1970 2330 2390 2390
DIMENSIONS TILT OF MAST/FORK CARRIAGE FORWARD/BACKWARD α/β 6/12 6/12 6/12 6/12
HEIGHT OF MAST,LOWERED h1(MM) 3100 3625 3860 3860
LIFT HEIGHT h3(MM) 3000 3500 3500 3500
HEIGHT OF MAST,EXTENED h4(MM) 4600 5375 5610 5610
HEIGHT OF OVERHEAD GUARD (CABIN) h6(MM) 3000 3365 3510 3510
OVERALL LENGTH (WITH FORK) l1(MM) 6055 7640 8340 9190
OVERALL WIDTH b1/b2(MM) 2250 2750 3050 3050
FORK DIMENSIONS(LxWxT) s/e(MM) 1200*180*90 1800*220*100 2000*260*100 2440*300*110
TURNING RADIUS Wa(MM) 4450 5800 6250 6700
PERFORMANCE DATA TRAVEL SPEED,LADEN/UNLADEN KM/H 23 / 26 26 / 30 26 / 30 25 / 29
LIFT SPEED,LADEN/UNLADEN MM/S 220 / 270 250 / 260 260 / 270 260 / 270
LOWERING SPEED(LOAD/UNLOAD) MM/S 450 / 300 430 / 330 310 / 260 315 / 260
MAXIMUM GRADEABILITY,LADEN/UNLADEN 20 / 22 20 / 21 20 / 22 20 / 21
SERVICE BRAKE HYDAULIC CLAMP DISC HYDAULIC CLAMP DISC HYDAULIC CLAMP DISC HYDAULIC CLAMP DISC
ADDITON DATA Rated voltage V 618 600 531 618
Traction KN 90 150 170 170
Power Consumption Rate KW 15 20 24 28
Power Reserves KW 141 175 240 282
Working Hour H 8,-10, 8,-10, 8,-10, 8,-10,
Driving Motor Power KW 80 80 100 120
Hydraulic Pump Motor Power KW 50 50 90 90

electric 25 ton forklift 1.JPG

electric 25 ton forklift 2.JPG

electric 25 ton forklift 6.JPG

electric 25 ton forklift 4.JPG
