18W power adapter-KA03-18W
Inquire NowDescription
The 18W Power Adapter KA03-18W is a versatile and efficient power supply unit designed for various applications including wireless communication electronics, network hardware, personal digital devices, audio and video equipment, medical devices, and home appliances. This power adapter ensures a reliable power supply with a wide input voltage range and multiple protective features, making it a safe choice for your electronic needs.
Featuring a compact design, the KA03-18W delivers an output voltage of 5.0-24V and an output current of up to 3A, accommodating a variety of devices. It operates efficiently with a maximum no-load power consumption of only 0.3W and a conversion efficiency exceeding 75%. Its built-in protections safeguard against over-current, over-voltage, over-temperature, and short-circuits, ensuring the longevity and reliability of your connected devices.
Specifications
| Attribute | Details |
|---|---|
| Input Voltage | 100~240Vac (Range: 90~264Vac) |
| Input Current | 0.5A max |
| Frequency | 50/60Hz (Frequency range: 47~63Hz) |
| Output Voltage | 5.0-24V |
| Output Current | 0-3A |
| Ripple & Noise | 150mV max |
| Power Consumption at No Load | 0.3W max |
| Conversion Efficiency | Greater than 75% |
| Voltage Regulation/Load Regulation | ±5% |
| Hi-pot Test | 3000 VAC/1min/5mA |
| Leakage Current | 0.25mA max @ 240 VAC |
| Operating Temperature | 0~40℃ |
| Safety Standard | UL/EN60950/GB4943 |
| EMC Standards | EN55022 class B / FCC Part 15 class B; EN55024/A1:2001/EN61000 |
Additional Information
Ideal for a multitude of uses, the KA03-18W power adapter is built to provide safe and efficient power for your essential devices. Ensure optimal performance and safety by adhering to the specified operating temperatures and electrical standards.
