1JP300 Laser land leveling machines
Inquire NowDescription
The 1JP300 Laser Land Leveling Machine is an advanced solution for achieving precise land leveling. Designed for efficiency and durability, this state-of-the-art grader is manufactured in Jiangsu, China, by Yuansheng. With its innovative laser technology, the 1JP300 ensures optimal ground uniformity, making it an essential tool for agricultural and construction applications. This machine is new and comes packaged in standard export packing, ready for delivery within 15 days after payment.
Specifications
| Parameter | Unit | 1JP-250 | 1JP-300 | 1JP-350 |
|---|---|---|---|---|
| Wide work | Mm | 2500 | 3000 | 3500 |
| Auxiliary power | KW | 55-65 | 65-88 | 88-120 |
| Operation efficiency | K㎡/h | 1.3-1.8 | 1.6-2.0 | 1.9-2.3 |
| Work speed | Km/h | 5-15 | ||
| Working stroke | Mm | 500 | ||
| The maximum penetration depth | Mm | 240 | ||
| A transmitter / receiver model | / | LS709/LS526 | ||
| The receiving controller working voltage | V | 11-30DC | ||
| Automatic leveling angle | ° | ± 5 | ||
| Signal receiving angle | ° | 360 | ||
| Flatness | Mm/100 ㎡ | ± 15 | ||
| Scraper lifting speed | Mm/s | L = 50 reduced ≥ 60 | ||
| Cylinder settlement | Mm/h | 12 | ||
| Working angle | ° | 10 + 2 | ||
| Hydraulic oil pressure | MPa | 16 + 0.5 | ||
| Tread | Mm | 1790 | 1990 | 2190 |
| The tire model | / | 235/85R16 | ||
| Air pressure | KPa | 200-250 | ||
| Structure type | / | Traction type | ||
| Environmental temperature | °C | 5-40 | ||
| Size and shape | Long mm | 3000 | 3000 | 3000 |
| Wide mm | 2650 | 3050 | 3550 | |
| High mm | 3650 | 3650 | 3650 | |
| The weight of the whole machine | Kg | 800 | 1000 | 1500 |
Additional Information
- Packaging: Standard exporting packing
- Delivery Time: 15 days after payment receipt
