OEM ODM 2.5 Ton Diesel Small Forklift
Description
Introducing the 2.5 Ton Diesel Small Forklift, a cutting-edge solution designed to elevate efficiency and productivity in material handling. This innovative forklift combines advanced hydraulic technology with user-friendly features, ensuring that it meets the demands of managers, drivers, and the goods being transported. With a focus on energy savings and high performance, this forklift sets a new industry standard.
The Socma small and big forklift series showcases a radical design that prioritizes operator comfort and safety. Equipped with a removable side cover for easy inspection and repairs, integrated electric components for convenient maintenance, and an adjustable seat to reduce driver fatigue, this forklift ensures a seamless operational experience. Key features include a powerful yet efficient diesel engine, enhanced cooling systems, and superior noise reduction capabilities, making it an excellent choice for diverse operational environments.
Specifications
| Parameter | Unit | Value |
|---|---|---|
| Model | FD25T | |
| Power Unit | Diesel | |
| Operator Type | Driver/seat | |
| Transmission Box Type | Electronic hydraulic transmission | |
| Rated Capacity | kg | 2500 |
| Load Center | mm | 500 |
| Max. Lifting Height | mm | 3000 |
| Tire Type | Pneumatic Tyre | |
| Tire Number – Front | 2 | |
| Tire Number – Rear | 2 | |
| Tire Size – Front | 7.00-12-12PR | |
| Tire Size – Rear | 6.0-9-10PR | |
| Overall Length (without fork) | mm | 2605 |
| Overall Width | mm | 1150 |
| Overhead Guard Height | mm | 2090 |
| Fork Size (L×W×T) | mm | 1220×122×40 |
| Truck Weight | kg | 3680 |
| Fuel Tank Capacity | L | 70 |
Additional Information
- Removable side cover for easy inspection and repairs.
- Integrated control box simplifies maintenance and inspection.
- Enhanced cooling system using aluminum heat sink.
- Noise reduction with a large double muffler.
- New suspension system for operator comfort.
- Lower step height for easier entry and exit.
- Double protection brake lever to prevent misuse.
