200kw VMAN biogas generator
Inquire NowDescription
The 200kW VMAN biogas generator is a powerful and efficient energy solution designed for various applications. This generator harnesses biogas to deliver a consistent power output of 200 kW, making it ideal for both residential and commercial uses. With its robust construction and advanced engineering, it ensures reliability and longevity. The generator features a four-stroke, water-cooled V8-type engine, ensuring efficient operation even under demanding conditions. Equipped with a high-efficiency alternator and a sophisticated control system, this generator guarantees optimal performance and ease of use, making it an excellent choice for sustainable energy production.
Specifications
| Attribute | Details |
|---|---|
| Model | YDNV-200 |
| Rated Power (kW/KVA) | 200/250 |
| Rated Voltage (V) | 220/380 |
| Frequency (Hz) | 50 |
| Rated Current (A) | 360 |
| Size (mm) | 2850 x 1400 x 1950 |
| Weight (kg) | 3100 |
| Engine Model | DT15 |
| Engine Type | Four-stroke, Water-cooling, V8-type |
| Engine Rated Power (kW) | 240 |
| Engine Rated Speed (rpm) | 1500 |
| Cylinder Number | 12 |
| Bore * Stroke (mm) | 128 x 142 |
| Cooling Method | Water-cooling |
| Oil Consumption (g/KWH) | ≤1 |
| Gas Consumption (Nm³) | ≤90/Hour @ 100% Load |
| Starting Method | 24V DC |
| Alternator Brand | FARRAND |
| Alternator Model | FLD-200 |
| Alternator Efficiency | 94.5% |
| Voltage Regulation | ≦±1 |
| Excitation Mode | Brushless, Self Excitation |
| Insulation Class | H |
| Control System Model | DES 6020 |
| Working Voltage | DC8.0V – DC35.0V |
| Control System Dimensions | 266 mm x 182 mm x 45 mm |
| Control System Panel Cutout | 214 mm x 160 mm |
| Working Condition | Temperature: (-25~+70)°C Humidity: (20~93)% |
| Control System Weight | 0.95 kg |
Additional Information
- Ideal for sustainable energy generation.
- Designed for reliable performance in various environmental conditions.
- Low oil and gas consumption for cost-effective operation.
