22mm OD Planetary Gearbox,
Permissible Load Range: 0.03N.m~0.3N.m
Motor Technical Data
| TYPE |
|
|
|
|
|
|
|
|
|
| Ratedvoltage |
No-loadspeed |
No-loadcurrent |
Ratedspeed |
Ratedtorque |
Outputpower |
Ratedcurrent |
Stalltorque |
Stallcurrent |
| VDC |
r/min |
mA |
r/min |
mN.m |
W |
mA |
mN.m |
A |
| 20ZY32-1280 |
12 |
8000 |
70 |
6700 |
2.2 |
1.5 |
200 |
13.9 |
1.07 |
| 20ZY32-1295 |
12 |
9500 |
70 |
7800 |
2.3 |
1.9 |
240 |
17.5 |
1.51 |
| 20ZY32-2480 |
24 |
8000 |
40 |
6700 |
2.3 |
1.6 |
110 |
15.0 |
0.58 |
Gear Motor Technical Data
20ZY32-1280 DC Motor
| Reduction ratio |
4 |
4.75 |
16 |
19 |
22 |
64 |
76 |
90 |
107 |
256 |
304 |
364 |
429 |
509 |
| Number of gear trains |
1 |
1 |
2 |
2 |
2 |
3 |
3 |
3 |
3 |
4 |
4 |
4 |
4 |
4 |
| Length(L) mm |
14.4 |
14.4 |
17.8 |
17.8 |
17.8 |
21.5 |
21.5 |
21.5 |
21.5 |
25.2 |
25.2 |
25.2 |
25.2 |
25.2 |
| No-load speed r/min |
2000 |
1684 |
500 |
421 |
364 |
125 |
105 |
89 |
75 |
31 |
26 |
22 |
19 |
16 |
| Rated speed r/min |
1675 |
1411 |
419 |
353 |
305 |
105 |
88 |
74 |
63 |
26 |
22 |
18 |
16 |
13 |
| Rated torque N.m |
0.008 |
0.009 |
0.029 |
0.034 |
0.039 |
0.10 |
0.12 |
0.14 |
0.17 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
| Max. permissible load in a short time N.m |
0.09 |
0.09 |
0.45 |
0.45 |
0.45 |
0.75 |
0.75 |
0.75 |
0.75 |
0.75 |
0.9 |
0.9 |
0.9 |
0.9 |
20ZY32-1295 DC Motor
| Reduction ratio |
4 |
4.75 |
16 |
19 |
22 |
64 |
76 |
90 |
107 |
256 |
304 |
364 |
429 |
509 |
| Number of gear trains |
1 |
1 |
2 |
2 |
2 |
3 |
3 |
3 |
3 |
4 |
4 |
4 |
4 |
4 |
| Length(L) mm |
14.4 |
14.4 |
17.8 |
17.8 |
17.8 |
21.5 |
21.5 |
21.5 |
21.5 |
25.2 |
25.2 |
25.2 |
25.2 |
25.2 |
| No-load speed r/min |
2375 |
2000 |
594 |
500 |
432 |
148 |
125 |
106 |
89 |
37 |
31 |
26 |
22 |
19 |
| Rated speed r/min |
1950 |
1642 |
488 |
411 |
355 |
122 |
103 |
87 |
78 |
30 |
26 |
21 |
18 |
15 |
| Rated torque N.m |
0.008 |
0.010 |
0.030 |
0.035 |
0.041 |
0.11 |
0.13 |
0.15 |
0.18 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
| Max. permissible load in a short time N.m |
0.09 |
0.09 |
0.45 |
0.45 |
0.45 |
0.75 |
0.75 |
0.75 |
0.75 |
0.75 |
0.9 |
0.9 |
0.9 |
0.9 |
20ZY32-2480DC Motor
| Reduction ratio |
4 |
4.75 |
16 |
19 |
22 |
64 |
76 |
90 |
107 |
256 |
304 |
364 |
429 |
509 |
| Number of gear trains |
1 |
1 |
2 |
2 |
2 |
3 |
3 |
3 |
3 |
4 |
4 |
4 |
4 |
4 |
| Length(L) mm |
14.4 |
14.4 |
17.8 |
17.8 |
17.8 |
21.5 |
21.5 |
21.5 |
21.5 |
25.2 |
25.2 |
25.2 |
25.2 |
25.2 |
| No-load speed r/min |
2000 |
1684 |
500 |
421 |
364 |
125 |
105 |
89 |
75 |
31 |
26 |
22 |
19 |
16 |
| Rated speed r/min |
1675 |
1411 |
419 |
353 |
305 |
105 |
88 |
74 |
63 |
26 |
22 |
18 |
16 |
13 |
| Rated torque N.m |
0.008 |
0.010 |
0.030 |
0.035 |
0.041 |
0.11 |
0.13 |
0.15 |
0.18 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
| Max. permissible load in a short time N.m |
0.09 |
0.09 |
0.45 |
0.45 |
0.45 |
0.75 |
0.75 |
0.75 |
0.75 |
0.75 |
0.9 |
0.9 |
0.9 |
|
