25KVA Widely Used 20KW Power Generating Plant Silent Diesel Generator
Inquire NowDescription
Experience the power of the 25KVA Silent Diesel Generator, designed to deliver high-efficiency electric power for your daily needs. This robust generating plant offers a reliable output of 20KW, enabling continuous operation for up to 8 hours, making it an ideal solution for various applications, from residential to commercial uses. The generator operates quietly, ensuring minimal disruption in any environment.
Specifications
| Attribute | Units | Details |
|---|---|---|
| Rated Power | kw/kVA | 20/25 |
| Max Power | kw/kVA | 22/28 |
| Frequency | Hz | 60 |
| Voltage | V | 220~480 |
| Current | A | 38 |
| Controller | COMAP MRS10 | |
| Battery | Ah | 1*12V-80 |
| Fuel Tank Capacity | L | 100 |
| Cooling Fluid Volume | L | 10 |
| Fuel Consumption (50% Loading) | L/kw hr. | 0.3 |
| Running Time under 50% Load | hr. | 25 |
| Noise Level behind 7 Meters | dBA | 68 |
| Engine | YSD490D | |
| Power Output | kW/1800rpm | 25 |
| Start Method | Elec. Start | |
| Displacement | cc | 2.54 |
| Oil Capacity | L | 15 |
| Alternator | 184E | |
| Rated Power | kVA | 23/28.8 |
| Power Factor | Cosφ | 0.8 |
| Voltage Regulation | AVR/Blushless | |
| Product Dimension | mm | 1800*900*1100 |
Additional Information
- Net Weight: 970 kg
- Gross Weight: 1070 kg
