2axle or 3 Axle Flatbed Timber Semi Trialer for Sale
Inquire NowDescription
The 2axle or 3 Axle Flatbed Timber Semi Trailer is designed for heavy-duty transportation, specifically tailored for timber and other bulk materials. Its robust construction ensures durability and reliability, making it an essential asset for logistics and transportation businesses. With customizable options available, this semi-trailer can meet various loading requirements while providing excellent performance on the road.
Specifications
| Feature | Details |
|---|---|
| Outer Side Dimension (mm) | 12450 × 2490 × 1557 (3 axles) / 40FT 7160 × 2490 × 1557 (2 axles) / 20FT |
| Loading Capacity (Ton) | ≤ 45 T (40FT) / ≤ 30 T (20FT) |
| Axles | 13 T/PER, FUWA Brand, BPW Brand, or Tianchi |
| Tire | 12.00R22.5 or 315/80R22.5 (China Brand or according to customer requirement) |
| Rim | 9.00-22.5 (China Brand) |
| Suspension | Mechanical (Germany Type or America Type) or Air (China brand or BPW brand) |
| Spring Leaf | 90(W)mm * 13(Thickness)mm * 10 Layer or 100mm * 12mm * 12 |
| King Pin | JOST brand 2.0 or 3.5 inch bolts type or Welding type |
| Support Leg | JOST brand D200T or China brand 28 Tons (Double speed) |
| Main Beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm; Material is Q345B Steel. |
| Side Beam | 16mm or 18mm channel steel (Material is Q235 steel). |
| Brake Chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber (TKL brand); one piece of 45L air tanks |
| Twist Locks | Four, Eight or Twelve pieces (Lifting type or Twist Screw Type) |
| Valve | WABCO valve |
| ABS | Optional |
| Light | LED or Normal light |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Tool Box | One piece, 1m × 0.5m × 0.5m (Size can be chosen freely) equipped with 1 unit Tire spanner, 1 unit gudgeon sleeve, and 1 unit cranking bar |
| Painting | Complete chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Shipping Terms | Transport by bulk cargo carrier, RORO or 40HQ container. |
Additional Information
This versatile flatbed trailer is ideal for transporting timber, ensuring secure load stability and easy handling. Its durable materials and advanced design make it a reliable choice for heavy-duty tasks. Consider this semi-trailer for your logistics needs to enhance efficiency and safety in transportation.
