Description

The 2CY gear pump is an essential component in various fluid transportation systems, designed for versatility and efficiency. This pump operates seamlessly as a transmission and booster pump in oil transportation, a fuel pump for conveying, pressurizing, and spraying in fuel systems, and a hydraulic pump to provide hydraulic power in hydraulic transmission systems. Additionally, it serves as a lubricating oil pump across all industrial fields.

Engineered to convey lubricating oil and similar liquids without solid particles or fibers, the 2CY gear pump excels in environments where temperatures do not exceed 300°C and viscosities range from 5×10^-6 to 1.5×10^-3 m²/s. By reducing the pump speed, it can handle viscosities up to 50000 mm²/s, making it a robust solution for demanding applications.

Specifications

Additional Information

The 2CY gear pump features a robust structure composed of high-quality gears, a durable pump body, and an innovative bearing sleeve design. The pump is equipped with a unique shaft end seal, which can include an optional magnetic drive for zero leakage. The gear’s hardness and wear resistance are enhanced through nitriding, ensuring longevity and reliability. The lubrication of all internal components is achieved automatically via the conveying medium during operation, promoting efficiency and reducing maintenance needs.
