2V80F-A （Lifan V-twin Gasoline engine)
Inquire NowDescription
The 2V80F-A Lifan V-twin Gasoline Engine is a robust and efficient power source designed for various applications. This 4-stroke engine features a V-TWIN cylinder configuration, ensuring smooth operation and high performance. With a bore and stroke of 80mm and 72mm respectively, it boasts a displacement of 724ml, making it ideal for tasks that require reliable power output.
Engineered with a compression ratio of 8.5:1, the 2V80F-A delivers a maximum power output of 18 kW at 3600 RPM, with a recommended operating power of 16.5 kW at the same RPM. Its impressive torque of 68 N.m at 2880 RPM ensures that it can handle demanding workloads with ease. The ignition system is a non-contact transistorized ignition (TCI), providing reliable starts with its electric start model.
Designed with user convenience in mind, the air cleaner is a semi-dry type, and the engine has a fuel consumption rate of 370 g/kW.h, making it economical for long-term use. With an engine oil capacity of 1.4 liters and a dry weight of 47 kg, this engine strikes a balance between power and portability, making it a perfect choice for various machinery and equipment.
Specifications
| Attribute | Details |
|---|---|
| Engine Type | V-TWIN-cylinder 4-stroke, forced air-cooled |
| Bore x Stroke (mm) | 80 x 72 |
| Displacement (ml) | 724 |
| Compression Ratio | 8.5:1 |
| Max Power Output (kW/rpm) | 18/3600 |
| Recommended Power Usage (kW/rpm) | 16.5/3600 |
| Max Torque (N.m/rpm) | 68/2880 |
| Ignition System | Non-contact transistorized ignition (TCI) |
| Start Model | Electric |
| Air Cleaner | Semi-dry type |
| Fuel Consumption (g/kW.h) | 370 |
| Engine Oil Capacity (L) | 1.4 |
| Dry Weight (kg) | 47 |
| Carton Dimension (L x W x H mm) | 705 x 570 x 600 |
| 20GP/40GP/40HQ | 96/201/268 |
