OEM ODM 3.5 Ton Telescopic Boom Forklift Truck Lift Height 7 Meter
Description
The 3.5 Ton Telescopic Boom Forklift Truck is an innovative loading and unloading machine designed for high efficiency and adaptability across various applications. With a lift height of up to 7 meters, this versatile forklift excels in lifting, stacking, and transporting cargoes, making it suitable for use in factories, docks, freight yards, and construction sites. The forklift is equipped with forks and a side shifter, allowing for enhanced operational capabilities.
Powered by a well-known brand diesel engine that adheres to National III emissions standards, this forklift offers robust power while remaining energy-efficient and environmentally friendly. Key features include:
- Double turbo hydraulic torque converter with a stepless speed change system for smooth operation.
- Advanced hydraulic system that reduces fuel and energy consumption.
- Full hydraulic coaxial flow amplification steering system for agile maneuverability.
- Rugged front wheel drive with a rigid suspension structure for superior load capacity.
- Durable chassis with an integral frame to ensure high reliability and performance.
- Standard features including forks, bucket, extension forks, and optional attachments for various tasks.
- Comfort-focused design with an adjustable air seat, joystick control, and climate control for an enhanced operator experience.
Specifications
| Items | Unit | Deviation allowed | HNT35-4 |
|---|---|---|---|
| Rated load | kg | – | 3500 |
| Load center | mm | – | 500 |
| Load capacity @ max. Forward reach | kg | – | 1550 |
| Basic boom max. Lifting height | mm | ±1.5% | 4850 |
| Max. Lifting height | mm | ±1.5% | 7000 |
| Max. Horizontal reach | mm | ±1.5% | 3350 |
| Min. Horizontal reach | mm | ±1.5% | 930 |
| Min. Ground clearance | mm | ±1.5% | 400 |
| Min. Turning radius (outer tyre center) | mm | ≤105% | 6200 |
| Operating weight | kg | ±5% | 9000 |
| Overall length (with fork) | mm | ±2% | 5730 |
| Overall width | mm | ±2% | 2390 |
| Overall height | mm | ±2% | 2485 |
| Wheel tread | mm | ±1% | 1870 |
| Wheel base | mm | ±1% | 2700 |
| Rated power / Rated turning speed | kW/rpm | – | 60/2000 |
| Max. Travelling speed (unloaded) | km/h | ±10% | 30 |
| Gradeability | % | – | ≥30% |
| Front Tyre | – | – | 16/70-24 |
| Rear Tyre | – | – | 10.00-20-16 |
| Engine | – | National 2 | 4BTA3.9-C80II |
| – | – | National 3 | QSB3.9-C80 |
Additional Information
This forklift features a luxury cabin design that provides a wide view, low noise levels, and effective sealing. Additionally, it is equipped with an electronic handbrake and off-bridge function for improved operability and efficiency, making it suitable for a range of working conditions.
