32kW R series generator engine
Inquire NowDescription
The 32kW R Series Generator Engine is a powerhouse designed for demanding applications, delivering reliable performance for your energy needs. This heavy-duty diesel engine is specifically crafted for 30kVA generator sets operating at 1500rpm, ensuring efficiency and durability. With its British Ricardo design, this engine boasts a high reliability factor, low fuel consumption, and easy maintenance, making it a top choice for both commercial and industrial use.
- Heavy Duty Engine: Engineered for tough conditions.
- British Ricardo Design: Infusing quality and performance.
- High Reliability: Built to perform consistently under pressure.
- Low Fuel Consumption: Optimized for efficiency.
- Easy Maintenance: Designed with user-friendliness in mind.
Specifications
| Attribute | Details |
|---|---|
| Engine Model | PHF3032ZD |
| Prime Power (Kw) | 32 |
| Type | 4 strokes, water-cooled in line, N.A. |
| Rating Speed (r/min) | 1500 |
| Highest and Lowest No-Loading Speed (r/min) | 1575 / 750 |
| Combustion Type | Direct injection |
| Cylinder No and Type | 3 / Wet liner |
| Bore X Stroke (mm) | 105 x 120 |
| Total Displacement (L) | 3.117 |
| Compression Ratio | 17:1 |
| Firing Order | 1-2-3 |
| Injection Timing | 6° |
| Dry Weight (kg) | 385 |
| Dimension (L*W*H) (mm) | 842 x 550 x 980 |
| Direction of Rotation | Counter clockwise viewed from flywheel |
Additional Information
This engine is designed for optimal performance under heavy loads, ensuring that you have a reliable power source whenever you need it. Regular maintenance will enhance its longevity and efficiency, making it a worthwhile investment for your power generation needs.
