36KV Drop-out Fuse Cutout Fuerte design
Inquire NowDescription
The 36KV Drop-out Fuse Cutout features a robust outdoor design that serves as an essential protection device for power systems, guarding against overloads and short-circuit failures. This unit is rated for voltages between 11kV and 36kV and adheres to IEC 600282-2 standards. Its high over-current protection capability, combined with superior breaking current performance, makes it a reliable choice for industrial applications. Notably, it boasts high industrial frequency withstand voltage and mechanical strength, ensuring durability and efficiency. Each unit undergoes rigorous testing to guarantee high quality and reliability.
Specifications
| Type | Unit | FSC-21 (100A) | FSC-21 (200A) |
|---|---|---|---|
| Rated Voltage | KV | 36 | 36 |
| Rated Current | A | 100 | 200 |
| Breaking Current | KA | 6 | 8 |
| Impulse Voltage | KV | 170 | 170 |
| Power-frequency withstand voltage | KV | 70 | 70 |
| Leakage Distance | mm | 660 | 660 |
| Weight | kg | 15.00 | 15.50 |
| Dimensions | cm | 59*37*17 | 59*37*17 |
Additional Information
- Port: Ningbo, Shanghai, Any port in China
- Payment Terms: T/T, L/C
- Packing: 1 pcs per carton lined with form, packed on a pallet. Custom packaging available upon request.
- Shipping: Options for sea, air, or express shipping are available as per customer preference.
- Delivery Time: Dependent on order quantity; regular delivery is within 35 days.
