3kW-30kW Off-Grid Solar System
Inquire NowDescription
The 3kW-30kW Off-Grid Solar System is designed to provide a reliable and environmentally friendly power solution for homes and businesses. This innovative system converts unstable DC power generated from solar panels into single-phase pure sine wave AC power, seamlessly supplying energy to your loads while automatically charging batteries. In times of insufficient solar energy, the stored battery power acts as a complete power source, ensuring uninterrupted energy supply. Additionally, this system can be supported by a grid or AC generator backup for extra reliability.
Notable features include a highly efficient inverter that integrates control and inverting functions, offering excellent compatibility and reliability with easy installation. The system operates with multiple functions and an automatic switch mode, providing a long-lasting, high-efficiency solution for all your power needs.
Specifications
| Model | SAP-FR/3KS | SAP-FR/5KS | SAP-FR/10KS | SAP-FR/15KS | SAP-FR/20KS | SAP-FR/30KS |
|---|---|---|---|---|---|---|
| Solar Panel | 8pcs-325W/24V | 12pcs-325W/24V | 24pcs-325W/24V | 36pcs-325W/24V | 48pcs-325W/24V | 72pcs-325W/24V |
| Inverter | 1pc-3KW | 1pc-5KW | 2pcs-5KW | 3pcs-5KW | 4pcs-5KW | 6pcs-5KW |
| Battery | 4pcs-12V150AH | 8pcs-12V150AH | 24pcs-2V500AH | 24pcs-2V800AH | 24pcs-2V1000AH | 24pcs-2V1500AH |
| Combiner Box | 1pc-6 in 1 | 1pc-6 in 1 | 2pcs-6 in 1 | 3pcs-6 in 1 | 4pcs-6 in 1 | 6pcs-6 in 1 |
| Accessory | 1set | 1set | 1set | 1set | 1set | 1set |
| Distribution Box | – | – | 1pc-10kW | 1pc-15kW | 1pc-20kW | 1pc-30kW |
Additional Information
Solar Panel Specifications:
| Model | SLP325-24 | SLP330-24 | SLP335-24 | SLP340-24 | SLP370S-24 | SLP375S-24 | SLP380S-24 | SLP385S-24 |
|---|---|---|---|---|---|---|---|---|
| Deviation of Rated Power (W) | 0~+5W | 0~+5W | 0~+5W | 0~+5W | 0~+5W | 0~+5W | 0~+5W | 0~+5W |
| Optimum Operating Voltage (Vmp) | 37.33V | 37.58V | 37.72V | 37.90V | 39.24V | 39.27V | 39.56V | 39.83V |
| Optimum Operating Current (Imp) | 8.72A | 8.80A | 8.88A | 8.97A | 9.43A | 9.55A | 9.60A | 9.67A |
| Open-Circuit Voltage (Voc) | 45.13V | 45.43V | 45.60V | 45.82V | 47.83V | 47.87V | 48.22V | 48.55V |
| Short-Circuit Current (Isc) | 9.23A | 9.31A | 9.40A | 9.49A | 9.90A | 10.03A | 10.0A | 10.15A |
| Standard Operating Temperature | 45±2°C | |||||||
| Arrangement of Cells | Polycrystalline/Monocrystalline solar cell-72(6×12) | |||||||
| Size of PV Module/Weight of PV Module | 1960mm x 992mm x 40mm / 22.1kg | |||||||
| Packing Information (Pallet) | 2005x1120x1130mm (26 pieces/pallet) | |||||||
