Description
The 3RP series cam rotor pump is a sophisticated rotary volumetric pump designed for high efficiency and extended service life. This pump is engineered to handle a wide range of applications, effectively conveying media at temperatures ranging from -30°C to 200°C, with viscosities up to 1.0×105 cSt. It is particularly suitable for transporting suspended liquids containing solid particles and for use in environments with high corrosive and hygienic requirements. Constructed with stainless steel components that come into contact with the medium, this pump guarantees durability and reliability, adapting to the physical characteristics of the medium by adjusting the pump speed.
Specifications
| Feature | Details |
|---|---|
| Temperature Range | -30°C to 200°C |
| Viscosity | Up to 1.0×105 cSt |
| Seal Options | Packing seal or mechanical seal |
| Gearbox Material | High strength cast iron |
| Application Areas | Food, beverage, wine, medicine, daily chemical, petrochemical |
| Sealing Material | Silicone rubber or polytetrafluoroethylene for corrosive mediums |
Additional Information
The rotor clearance can be adjusted without the need to remove the gearbox, enhancing maintenance efficiency. The O type sealing ring is specifically designed to ensure optimal performance under various conditions, making the 3RP series cam rotor pump a versatile choice for diverse industrial applications.
Images
