APPLICATIONS
? For water supply from wells or reservoirs.
? For domestic use, for civil and industrial applications.
? For garden use and irrigation.
OPERATING CONDITIONS
? Maximum fluid temperature up to +35°C
? Maximum sand content: 0.25%
? pH permissible range: 6.5 – 8.5
? Minimum well diameter: 3″ MOTOR AND PUMP REWINDABLE MOTOR, FILLED WITH EDIBLE OIL. Single-phase: 220V – 240V /50Hz Three-phase: 380V – 415V /50Hz Equip with start control box or digital auto-control box which build in capacitor & current mode thermal protector. Pumps are designed by casing stressed, pump sleeve with screw thread, single stage floating impellers. Curve tolerance according to ISO 9906 OPTIONS ON REQUEST ? Special mechanical seal ? Other voltages or frequency 60 Hz ? Single phase motor with built-in capacitor ? Inlet & Outlet are available with Casting or SS304 ? Oil Chamber is available with Brass or SS304 WARRANTY 1 year (according to our general sales conditions)
