Type
|
3TF-9/12
|
3TF-16/22
|
3TF-32
|
3TF-45/63
|
3TF-75/85
|
|
Mechanical Endurance(X106)
|
10
|
10
|
10
|
8
|
8
|
|
Conventional thermal current(A)
|
20
|
30
|
45
|
80
|
100
|
|
Rated insulation voltage(V)
|
660
|
660
|
660
|
1000
|
1000
|
|
Rated operating current(A)
|
AC-3
|
‘9/12
|
16/22
|
32
|
45/63
|
75/85
|
|
AC-4
|
3.3/4.3
|
7.7/8.5
|
15.6
|
24/28
|
34/42
|
|
Power of controllable motor(KW) AC-3
|
380V
|
4/5.5
|
7.5/11
|
15
|
22/30
|
37/45
|
|
660V
|
5.5/7.5
|
11
|
23
|
39/55
|
67
|
|
Power of controllable motor(KW) AC-4
|
380V
|
1.4/1.9
|
3.5/4
|
7.5
|
’12/14
|
17/21
|
|
660V
|
2.4/3.3
|
6/6.6
|
13
|
20.8/24
|
29.5/36
|
|
Frequency of operation (I/h)
|
AC-3
|
1000
|
750
|
750
|
1200/1000
|
1000/850
|
|
AC-4
|
250
|
250
|
250
|
400/300
|
300/250
|
|
Electrical endurance (X106)
|
AC-3
|
1.2
|
1.2
|
1.2
|
1.2
|
1.2
|
|
AC-4
|
0.2
|
0.2
|
0.2
|
0.2
|
0.2
|
|
Operating voltage range of coil
|
(0.8-1.1)Ue
|
|
Power consumption of coil
|
Atracting (VA)
|
10
|
10
|
12.1
|
17
|
32
|
|
Starting (VA)
|
68
|
69
|
101
|
183
|
330
|
|
Rated insulation voltage of auxiliary contacts(V)
|
690
|
690
|
690
|
690
|
690
|
690
|
|
Conventional thermal current of auxiliary contacts(A)
|
10
|
10
|
10
|
10
|
10
|
10
|
|
Rated operating current of auxiliary contacts(A)
|
AC15 380/220
|
’6/10
|
’6/10
|
’4/10
|
’4/10
|
’4/10
|
|
DC13 220v
|
0.45
|
0.45
|
0.45
|
0.45
|
0.45
|
|
Rated voltage of the control coil(V)
|
50HZ
|
24 36 48 110 127 220 380,etc
|
|
60HZ
|
24 110 220 440 etc
|
