4 Ton Diesel Small Forklift Attachment Paper Roll
Inquire NowDescription
The 4 Ton Diesel Small Forklift Attachment Paper Roll is a cutting-edge solution designed to enhance efficiency and save energy in material handling operations. This innovative forklift is specifically engineered to meet the demands of both managers and operators while ensuring the secure handling of piled goods. With a focus on high performance, the forklift integrates advanced hydraulic technology, delivering exceptional durability and reliable functionality. The design features a unique uploading system, an ergonomically designed cab, and user-friendly controls, all aimed at improving operational capacity and security. Users can expect remarkable comfort, especially during prolonged operations, thanks to its adjustable seating and improved suspension system.
Specifications
| Model | FD40T |
|---|---|
| Power Unit | Diesel |
| Operator Type | Driver/seat |
| Transmission Type | Electronic hydraulic transmission |
| Rated Capacity | 4000 kg |
| Load Center | 500 mm |
| Max. Lifting Height | 3000 mm |
| Tire Type | Solid Tyre |
| Tire Number | Front: 2, Rear: 2 |
| Tire Size | Front: 250-15-16PR, Rear: 6.5-10-10PR |
| Lifting Speed | Loaded: 480 mm/s, Unloaded: 520 mm/s |
| Lowering Speed | Loaded: 480 mm/s, Unloaded: 450 mm/s |
| Travelling Speed | Loaded: 19 km/h, Unloaded: 20 km/h |
| Overall Length | 2820 mm |
| Overall Width | 1300 mm |
| Overhead Guard Height | 2130 mm |
| Fork Size (L×W×T) | 1220×150×50 mm |
| Truck Weight | 5100 kg |
| Fuel Tank Capacity | 70 L |
Additional Information
- Removable side cover for easier inspection and repairs.
- Integrated control box for convenient maintenance.
- Enhanced cooling with aluminum heat sink and large double muffler for noise reduction.
- Adjustable seat and improved suspension for operator comfort.
- Lower step height facilitates easy entry and exit.
- Broad flat design for efficient steering.
- Embedded LCD instrument for safety with engine start lock when not in neutral.
- Double protection brake lever to prevent misuse.
- Advanced engineering for improved visibility and head protection during rain.
