4 way splitter
Inquire NowDescription
The 4 Way Splitter is an essential component designed to efficiently distribute high-frequency signals across multiple outputs. Ideal for both residential and commercial applications, this splitter boasts a screening factor of 5-1218MHz with a minimum of 100dB, ensuring minimal signal loss and interference. Each port is equipped with F-type connectors, ensuring compatibility with standard coaxial cables and maintaining a 75 Ohm impedance for optimal performance. Crafted from durable zinc die-cast housing and finished with nickel plating, this splitter is built to withstand the rigors of use while ensuring reliable connectivity. Compliant with DOCSIS 3.1 standards, it guarantees seamless integration into modern cable systems.
Specifications
| Item Model | Frequency Range (MHz) | Insertion Loss (dB) | Mutual Isolation (dB) | Return Loss (dB) |
|---|---|---|---|---|
| 2 Way Splitter GC-1602D | 5-40 | ≤3.5 | ≥28 | ≥20 |
| 40-470 | ≤3.8 | ≥28 | ≥22 | |
| 470-860 | ≤3.9 | ≥28 | ≥20 | |
| 860-1000 | ≤4.0 | ≥28 | ≥20 | |
| 1000-1218 | ≤4.2 | ≥25 | ≥18 |
