42L6 AC Ammeter and Voltmeter
Inquire Now42L6 AC Ammeter and Voltmeter
Selection Guide
|
N |
input mode |
sequence |
type |
|
42 |
L：AC |
6 |
A：Ammeter V：Voltmeter W：Active power meter VAR:Reactive power meter Hz：Frequency table COS:Power factor meter |
Main features
■Show the trend of change, the reading is convenient
■Bolt fastening installation
Main technical parameters
|
Item |
Technical data |
|
National standard |
GB/T 7676.1~9 |
|
Accuracy class |
1.5 class、2.5 class |
|
puncture test |
frequency50Hz、voltage2000V、duration1min |
|
Environment condition |
temperature：-20～+40℃，relative humidity≤85%（25℃）；damping≤4s |
|
Resistance to mechanical properties |
Can withstand acceleration of 30m/s2 a and impact frequency per minute 80～120 times 2 hours of transport shock |
|
Operating position |
Vertical |
|
Outline overall and installing dimensions |
Outline dimension：120 mm×120 mm Installation dimensions：112 mm×112 mm |
