Description
The 4SDM2 is a versatile and reliable pump designed for a variety of applications including water supply from wells, reservoirs, domestic use, civil and industrial applications, as well as garden irrigation. It features a robust motor that is rewound and filled with edible oil, ensuring safe and efficient operation. Available in both single-phase and three-phase configurations, this pump is equipped with start control boxes or digital auto-control boxes, which include built-in capacitors and current mode thermal protection for enhanced safety.
Engineered with casing stressed design and a screw thread pump sleeve, the 4SDM2 utilizes single-stage floating impellers for optimal performance. Its operational capabilities allow for a maximum fluid temperature of +35°C, with a sand content tolerance of up to 0.25% and a pH range of 6.5 to 8.5. The pump requires a minimum well diameter of just 4 inches, making it suitable for a variety of installations.
Customization options are available upon request, including special mechanical seals, different voltages or frequencies (60Hz), and inlet/outlet material choices between casting or SS304. Warranty coverage lasts for one year, adhering to general sales conditions.
Specifications
| Feature | Details |
|---|---|
| Maximum Fluid Temperature | +35°C |
| Maximum Sand Content | 0.25% |
| pH Permissible Range | 6.5 – 8.5 |
| Minimum Well Diameter | 4 inches |
| Motor Type | Rewindable, filled with edible oil |
| Single-Phase Voltage | 220V – 240V / 50Hz |
| Three-Phase Voltage | 380V – 415V / 50Hz |
| Warranty | 1 year |
Additional Information
- Options for customization available upon request.
- Inlet & Outlet can be provided in casting or SS304.
- Oil chamber options include brass or SS304.
