5 Gallon water filling machine
Inquire NowDescription
The 5 Gallon Bottle Washing Filling Capping Machine Line is an essential piece of equipment for any facility focused on high-quality bottled water production. This cutting-edge machine is designed specifically for the efficient washing, filling, and capping of 5-gallon water bottles, making it ideal for mineral, distilled, and purified water production. Constructed from premium stainless steel, the machine offers durability and resistance to corrosion, ensuring a long service life and minimal maintenance.
Featuring advanced technology, this fully automatic system integrates machine, electronic, and pneumatic components for reliable operation. The unique washing system utilizes both inner and outer shower nozzles that incorporate special technology from a renowned American sprayer company, enabling thorough cleaning of each bottle. The machine operates smoothly due to its compact structure and high degree of automation.
Equipped with leading electrical components from respected brands such as SIEMENS and OMRON, along with pneumatic parts from AIRTAC, this machine guarantees performance and efficiency. The QGF type barreled water producing line is indeed the heart of any modern bottled water production facility.
Specifications
| Attribute | Linear | Rotary |
|---|---|---|
| Capacity | Up to 2000 BPH | Up to 3000 BPH |
| Station number | Up to 10 stations | Up to 20 stations |
| Control system | PLC control | PLC control |
| Control panel | Touchscreen and numeric | Touchscreen and numeric |
| Machine Frame | AISI304, thickness: 2mm-6mm | AISI304, thickness: 2mm-6mm |
| Board Material | AISI304, material thickness: 2mm | AISI304, material thickness: 2mm |
| Equipment Materials | AISI3016L and AISI304 | AISI3016L and AISI304 |
| Energy Supply | 380 V ±10% 3PH+N+PE | 380 V ±10% 3PH+N+PE |
| Operating Air Pressure | 6-10 bar | 6-10 bar |
Additional Information
Main Technical Standards:
- Air move parts: Yadeke
- SIEMENS AC products
- Stainless steel conveyor: 304 or 316
- Waterproof frame in rotor axis
- Brush speed control motor: 0.75 kW
- Dial wheel motor: 0.75 kW
- Washing pump: 0.37 kW
- Conveyor with motor: 0.27×3 kW
- Washing lotion with heating parts: 6 kW
