6.5KW to 2000KW AC Synchronous Stamford type brushless alternator
Inquire NowDescription
The AC Synchronous Stamford type brushless alternator, available in power ratings from 6.5KW to 2000KW, is engineered for high efficiency and top-quality performance. This versatile generator is ideal for various industrial applications, ensuring a reliable power supply with minimal maintenance due to its brushless design. The alternator features both single and double bearing options, catering to different operational preferences.
Key Features:
- Factory price for cost-effective solutions.
- High efficiency ensures optimal performance.
- Robust build quality for long-lasting use.
- Flexible configurations with single or double bearings.
It supports both 50Hz and 60Hz frequencies as per customer requirements, with voltage options ranging from 380V to 690V, and includes configurations for serial star, parallel star, and serial delta connections. This model is designed with a 12-lead reconnectable system, providing versatility in voltage and phase arrangements.
Specifications
| Model | PRIME OUTPUT (1500RPM/50HZ) 400V | PRIME OUTPUT (1800RPM/60HZ) 440V |
|---|---|---|
| BC164A | KW: 6.5, KVA: 8.1, A: 11.7 | KW: 8.2, KVA: 10.2, A: 14.8 |
| BC164B | KW: 8.8, KVA: 11, A: 15.8 | KW: 11, KVA: 13.8, A: 19.88 |
| BC164C | KW: 10.8, KVA: 13.5, A: 19.4 | KW: 13.5, KVA: 16.9, A: 24.38 |
| BC164D | KW: 12.8, KVA: 16, A: 23 | KW: 16, KVA: 20, A: 28.88 |
| BC184E | KW: 18, KVA: 22.5, A: 32.4 | KW: 23, KVA: 28.8, A: 41.5 |
| BC184F | KW: 22, KVA: 27.5, A: 39.6 | KW: 27.5, KVA: 34.4, A: 49.68 |
| BC184G | KW: 25, KVA: 31.3, A: 45 | KW: 30, KVA: 37.5, A: 548 |
| BC184H | KW: 30, KVA: 37.5, A: 54 | KW: 37.5, KVA: 46.9, A: 67.68 |
| BC184J | KW: 34, KVA: 42.5, A: 61.3 | KW: 40, KVA: 50, A: 70 |
Additional Information
This alternator includes advanced insulation (H) and protection (IP21-23) features, ensuring durability and reliability in harsh environments. Components such as the rotor and exciter are specially impregnated with tropical-grade insulating oil and acid-resisting polyester resin, enhancing their mechanical strength. The automatic voltage regulator (AVR) system ensures stable voltage output with minimal radio interference, and an RFI noise filter is available for enhanced performance.
