| General Specification |
| Genset Prime Power |
7.2 kW |
| Rated Frequency |
50 Hz |
| Rated Voltage |
220V (1phase） |
| Power Outlet Sockets |
2×10A(220V 1phase） |
| Main Power Outlet Sockets |
1×63A(220V 1phase） |
| Sound Level |
65dB(A) at 7m |
| Type of Light |
LED (Chinese Brand) |
| Number & Power of Light |
6×400W |
| Luminous Flux |
6×39000 Lm |
| Light coverage |
2000 square meters |
| Anti-water Grade |
IP65 |
|
| Dimension |
| Dimensions (Folded) |
3.00*1.75* 2.25m(L*W*H) |
| Dimensions (Extended) |
3.00*2.94*9.00m (L*W*H) |
| Fuel Tank Capacity |
90 L |
| Tank Operating Hours |
45 Hr |
|
| LED Light Specification |
| LED Light Model |
JR303-400L |
| Rated Power |
400W |
| Luminous Flux |
39000 Lm |
| Power Factor |
0.98 |
| Light Effect |
95Lm/W |
| Colour Temperature/Wavelength |
4985 K m |
| Color rendering index |
75.9 Ra |
|
| Alternator Specification |
| Alternator Model |
LT3-160/4 |
| Alternator Manufacturer |
MECC |
| Alternator Type |
Brushless & Single phase |
| Rated Frequency |
220 V |
| Rated Output Power |
8.0 kW |
| Insulation Grade |
H |
| Protection Grade |
IP23 |
|
| Engine Specification |
| Engine Model |
403D-11G |
| Manufacturer |
Perkins |
| Number of Cylinders |
3 |
| Cylinder arrangement |
Vertical in-line |
| Cycle |
Four stroke |
| Aspiration |
Natural |
| Bore×Stroke (mm×mm) |
78×81 |
| Displacement (Liter) |
1.131 |
| Compression Ratio |
23.:1 |
| Prime Power/Speed (kW/rpm) |
8.4/1500 |
| Standby Power/Speed (kW/rpm) |
9.3/1500 |
| Speed Governor |
Mechanical |
| Cooling System |
Water-cooled |
|
