60m spray range multi-function stationary type spray cannnon
Inquire NowDescription
The TMD-M06 Multi-Function Spray Cannon is an innovative solution designed for efficient disinfection and dust control in various environments. With an impressive spray range of up to 60 meters, this stationary unit effectively disperses water mist to enhance air quality and reduce airborne particles. The cannon features a robust construction and advanced control methods, including a remote controller and touch panel, ensuring ease of operation. Ideal for industrial, agricultural, or municipal applications, the TMD-M06 is a powerful tool for maintaining a cleaner and safer atmosphere.
Specifications
| Feature | Details |
|---|---|
| Model | TMD-M06 |
| Spray Range | 60m |
| Total Power | 27.5kw |
| Water Consumption | 8.5m³/h |
| Dimensions (L*W*H) | 1900*1155*2365mm |
| Weight | 1200kg (electric) |
| Control Method | Remote controller and touch panel |
| IP Grade | IP55 |
| Noise Level | 70dB at 7.5 |
| Turning Degree | ±180° |
| Pitching Degree | Up: 55 / Down: -10 |
| Diameter of Water Mist Particle | 20-150μm |
| Fan Power | 18.5kw |
| Water Pump Power | 7.5kw |
| Water Pump Pressure | 1.5-2Mpa |
| Usage Temperature (℃) | 0-50 |
| Power Supply | AC/3-phase/375V-415V/50HZ |
| Nozzles Quantity | 78pcs |
Additional Information
The TMD-M06 Spray Cannon is suitable for various applications, providing optimal performance in dust suppression and disinfection. Ensure proper maintenance for longevity and efficiency.
