6SRM10
Inquire NowDescription
The 6SRM10 is a versatile submersible pump designed specifically for efficient water supply from wells or reservoirs. Ideal for both domestic and industrial applications, it excels in garden use and irrigation. This pump operates effectively under varying conditions, ensuring reliable performance for a range of water management needs.
Crafted with a rewindable motor filled with edible oil, the 6SRM10 ensures smooth operation and longevity. It caters to both single-phase (220V – 240V / 50Hz) and three-phase (380V – 415V / 50Hz) electrical systems, featuring a start control box or a digital auto-control box equipped with a capacitor and thermal protector. The pump is designed with a robust casing, a pump sleeve with screw thread, and single-stage floating impellers, meeting industry standards for performance.
Specifications
| Feature | Details |
|---|---|
| Applications | Water supply from wells or reservoirs, domestic use, civil and industrial applications, garden use, and irrigation |
| Maximum Fluid Temperature | +35°C |
| Maximum Sand Content | 0.25% |
| Permissible pH Range | 6.5 – 8.5 |
| Minimum Well Diameter | 6 inches |
| Motor Type | Rewindable motor filled with edible oil |
| Power Supply | Single-phase: 220V – 240V / 50Hz, Three-phase: 380V – 415V / 50Hz |
| Options on Request | Special mechanical seal, other voltages or frequency (60 Hz) |
| Warranty | 1 year (according to general sales conditions) |
Additional Information
- Designed to ensure efficient water supply and reliable performance
- Equipped with a start control box or digital auto-control box
- Meets ISO 9906 curve tolerance standards
