7 way trailer junction box
Inquire NowDescription
The 7-way trailer junction box is an essential component for ensuring safe and secure wiring connections on a variety of towed vehicles including RVs, trailers, campers, and caravans. This junction box is designed with user-friendliness in mind, featuring a color-coded 7-pole configuration that simplifies the connection process. Each pole is clearly marked on the base, allowing for quick identification and installation.
Key functions include:
- Brown: Right stop and turn
- Red: Left stop and turn
- Green: Turn signal
- Blue: Electrical brake
- Yellow: Auxiliary
- Black: 12-volt charge line
- White: Ground
Constructed from commercial-grade black plastic, the junction box features a secure cover that fits over the base and is held in place by fastening screws. It includes grommets to allow for wiring to pass through, ensuring weatherproofing and durability.
Specifications
| Feature | Description |
|---|---|
| Type | 7-Pole Junction Box |
| Material | Commercial Grade Black Plastic |
| Connection Type | 10-32 Thread with Nut |
| Weatherproofing | Includes Grommets |
| Mounting | Includes Mounting Screw Holes |
Additional Information
For optimal performance, ensure all connections are made securely. The junction box is designed for ease of installation, making it a reliable choice for your towing needs.
