OEM ODM AD1
Description
AD1 is a cutting-edge three-wheeled scooter designed for urban agility and comfort. Featuring an innovative independent four-arm front suspension, it offers exceptional stability and cornering capabilities, allowing riders to maneuver effortlessly through busy city streets. The patented dual front wheel structure enables a lean angle of 30 degrees, enhancing the riding experience.
With a sporty edge, the AD1 is lighter and more nimble than its counterpart, the AD3. It is powered by a water-cooled, single-cylinder engine, boasting a displacement of 188.6cc and delivering a peak power of 14.1kW (19PS) at 8250rpm. The maximum torque reaches 16.5N·m at 6500rpm, ensuring a thrilling ride.
Equipped with a large TFT LCD display, dual USB charging ports, and a spacious tail box, the AD1 prioritizes practicality and convenience. Additional features include a high windshield, foldable canopy, electric wiper, parking handbrake, and heating system, all designed to enhance rider comfort and safety.
Specifications
| Attribute | Value |
|---|---|
| Dimensions (LxWxH) (mm) | 2080 × 660 × 1715 |
| Wheelbase (mm) | 1460 |
| Dry Weight (kg) | 217 |
| Max Load (kg) | 382 |
| Max Speed (km/h) | 100 |
| Fuel Consumption (L/100km) | ≤ 2.9 |
| Engine Type | 1-cylinder, 4-stroke, DOHC, 4-valve, water-cooled, EFI |
| Bore x Stroke (mm) | 63.0 x 60.5 |
| Displacement (cc) | 188.6 |
| Compression Ratio | 12.1:1 |
| Max Power (kw/r/min) | 14.1/8250 |
| Max Torque (N.m/r/min) | 16.5/6500 |
| Ignition | E.C.U |
| Starter | Electric starting |
| Gear Type | Automatic |
| Transmission | CVT |
| Suspension (Fr./Rr) | Upside down hydraulic fork / Central Spring Shock Absorber |
| Tire Size (Fr./Rr) | 120/70-13 / 130/60-13 |
| Brake Type (Fr./Rr) | Disc/Disc ABS |
| Fuel Tank Capacity (L) | 9.2 |
| Battery | 12V9Ah |
