AD22C-16TE 16mm metal indicator light double color mini led lamp
Inquire NowDescription
The AD22C-16TE is a state-of-the-art 16mm metal indicator light featuring a double-color mini LED lamp. Engineered using advanced LED technology, this product is designed to replace older incandescent and neon lamps with a more efficient and long-lasting solution. Its compact size and lightweight design make it ideal for various applications while maintaining high brightness and reliability. The AD22 series is celebrated for its aesthetic appeal, robust construction, and thoughtful manufacturing, ensuring it meets the highest quality standards. With features including a polycarbonate lampshade for enhanced durability and anti-surge performance, this indicator light is a perfect choice for professionals seeking efficiency and style in their designs.
Specifications
| Specification | Details |
|---|---|
| Voltage of Working Frequency | 2.5kV (AC valid value), 1min |
| Insulated Resistance | ≥2MΩ |
| Voltage Wave Allowed by AC Indicator | ±20% |
| Continual Working Life | ≥30000h |
| Brightness | ≥60cd/m² |
| Index of Leakage CT1 | ≥100 |
| Protection Grade | IP40 (can be upgraded to IP67) |
| Using Frequency | N/A |
Additional Information
- Available in various designs to meet international standards.
- Equipped with a bolt-type connector for enhanced safety and convenience.
- Ideal for a wide range of applications, ensuring flexibility in design choices.
Product Show
