Agri disc harrow Small tractor disc harrow offset disk harrow
Inquire NowDescription
The Agri Disc Harrow is a highly efficient, tractor-mounted light disc harrow designed for small tractors ranging from 15 to 60 horsepower. This innovative tool is essential for preparing the soil for planting by effectively cleaning crop residue, breaking up hardened soil, and returning chopped straw to the ground. It excels in leveling the land and preparing heavy clay and weedy fields, ensuring a smooth and loosened soil surface after harrowing.
With its powerful performance and durability, the Agri Disc Harrow is engineered with precision. Its 65Mn spring steel discs and robust bearing assembly ensure longevity and reliability in tough farming conditions. Additionally, the adjustable working depth allows for customized operation, making it an ideal choice for varied agricultural applications.
Specifications
| Model | Working Width (mm) | Working Depth (mm) | Q’ty of Disc | Total Weight (kg) | Matched Power (hp) |
|---|---|---|---|---|---|
| 1BQX-1.1 | 1100 | 120 | 12 | 200 | 15 |
| 1BQX-1.3 | 1300 | 120 | 14 | 220 | 18 |
| 1BQX-1.5 | 1500 | 120 | 16 | 240 | 25 |
| 1BQX-1.7 | 1700 | 120 | 18 | 260 | 28 |
| 1BQX-1.9 | 1900 | 120 | 20 | 310 | 30 |
| 1BQX-2.3 | 2300 | 120 | 24 | 360 | 35 |
Additional Information
- Strong and durable bearing assembly ensures longevity.
- Equipped with scrapers for each disc blade to remove debris.
- Customizable working depth for various soil types.
