Air conditioner
Inquire Now
1.Indoor and outdoor units with air conditioning function;
2.Galvanized sheet metal structure and powder coating panel, soundproof panel;
3.Compressors and other accessories use world-renowned brands;
4.Double suction centrifugal fan unit;
5.Standard G4 filter configuration,F5-F8 can be optional, comply with CEN-EN, filter efficiency is as high as 90.1%;
6.Power distribution box, comply with IEC 204-1/EN60204-1;
7.The micro-processor controls the starting times of the compressor according to the principle of “first start, first stop”;
8.The standard configuration of this unit also includes thermal expansion valve, high/low pressure safety switch, visual fluid mirror and drying filter;
Features
1.Indoor and outdoor units with air conditioning function;
2.Galvanized sheet metal structure and powder coating panel, soundproof panel;
3.Compressors and other accessories use world-renowned brands;
4.Double suction centrifugal fan unit;
5.Standard G4 filter configuration,F5-F8 can be optional, comply with CEN-EN, filter efficiency is as high as 90.1%;
6.Power distribution box, comply with IEC 204-1/EN60204-1;
7.The micro-processor controls the starting times of the compressor according to the principle of “first start, first stop”;
8.The standard configuration of this unit also includes thermal expansion valve, high/low pressure safety switch, visual fluid mirror and drying filter;
Application
1.3G/4G/5G base station;
2.small and medium-sized database;
3.all kinds of outdoor room;
4.center substation, substation between equipments;
5.small and medium-sized communication room;
6.certain requirements of equipment for the temperature;
7.small and medium-sized computer room;
8.small and medium-sized warehouse,laboratory(according to the specific requirements for customization).
Specification
| Model | RCU/S | RCU/S | RCU/D | |||||||||||||||
| 0075 | 0125 | 0168 | 0200 | 0250 | 0305 | 0351 | 0405 | 0452 | 0356 | 0464 | 0501 | 0564 | 0635 | 0717 | 0802 | 0922 | 1010 | |
| Power(V/Ph/Hz) | 380/3N/50 | |||||||||||||||||
| Total cooling capacity (KW) | 8 | 13 | 17.2 | 20 | 25 | 30.5 | 35.1 | 40.5 | 45.2 | 35.6 | 48.5 | 50.1 | 56.4 | 63.5 | 71.7 | 80.2 | 92.2 | 101.0 |
| Sensible cooling capacity (KW) | 7.4 | 11.7 | 15.9 | 18.1 | 22.5 | 30 | 33.5 | 39.7 | 44 | 35.3 | 43.5 | 48.5 | 53.2 | 62.0 | 70.5 | 78.0 | 90.5 | 98.7 |
| SHR | 0.92 | 0.90 | 0.92 | 0.91 | 0.90 | 0.98 | 0.95 | 0.98 | 0.97 | 0.99 | 0.90 | 0.97 | 0.94 | 0.98 | 0.98 | 0.98 | 0.98 | 0.98 |
| Compressor | ||||||||||||||||||
| Quantity of compressor | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Input power (KW) | 1.87 | 3 | 3.69 | 4.2 | 4.91 | 6.01 | 6.3 | 7.66 | 8.64 | 7.27 | 9.62 | 10.5 | 12 | 12 | 13.9 | 15.9 | 17.9 | 21.9 |
| Fan | ||||||||||||||||||
| Air volume(m3/h) | 2200 | 2850 | 4750 | 4750 | 5750 | 8400 | 9180 | 13000 | 15200 | 11550 | 15200 | 15400 | 14850 | 21300 | 22000 | 23000 | 27000 | 28000 |
| AC fan power (KW) | 0.30 | 0.46 | 0.84 | 0.84 | 1.50 | 2.07 | 2.26 | 3.30 | 3.45 | 2.39 | 3.45 | 3.45 | 3.82 | 4.74 | 5.17 | 5.72 | 6.79 | 6.79 |
| EC fan power (KW) | No | No | No | No | No | 1.60 | 1.90 | 2.35 | 3.59 | 2.14 | 3.62 | 3.76 | 3.26 | 4.07 | 4.41 | 4.99 | 6.2 | 6.73 |
| External pressure (Pa) | 20-350 | |||||||||||||||||
| Noise(2)dB(A) | 52 | 53 | 56 | 56 | 57 | 65 | 67 | 62 | 65 | 60 | 65 | 65 | 65 | 56 | 57 | 59 | 64 | 65 |
| Humidifier (Kg/h) | ||||||||||||||||||
| Humidifying capacity | 3 | 3 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 8 | 8 | 8 | 8 | 8 |
| Heater power (KW) | 2.25 | 2.25 | 3.75 | 3.75 | 3.75 | 3.75 | 3.75 | 3.75 | 3.75 | 3.75 | 3.75 | 3.75 | 3.75 | 6 | 6 | 6 | 6 | 6 |
