1.Product Description
1. the advantage of shutter door bottom forming machine china
it has reasinable structure, beautiful appearance, with advantage of saving space, easy operate and especially welcomed by the costomer with limit area or site operation.
2. Main Parameter and specification of the shutter door bottom forming machine
We design each machine according to user requirement. Below techinical parameters can be adjusted if needed.
1. the name of the product: shutter door bottom forming machine
2.Main motor power: 3kw,3 phases
3.hydraulic motor power:3kw
4.Hydraulic Pressure:18-20Mpa
5.Voltage: 380V /3phase/ 50 HZ (or as your requirement)
6.Control system: PLC Delta Inverter
7.Main frame: 300MM H-Beam
8.Backboard Thickness:14MM
9.Chain Size: 20MM
10.Feeding Material:2.0MM
11.Feeding Thickness:2.0MM
| 12 | Feeding Width | according to your need | |||||
| 13 | Effective width | according to the profile | |||||
| 14 | Productivity | 8-12m/min | |||||
| 15 | Roll Station | 12 | |||||
| 16 | Roller Diameter | 50mm | |||||
| 17 | Roller material | 45# steel | |||||
| 18 | Cutter material | Cr12 , quenched | |||||
| 19 | Cr-Plating Size | 0.05mm | |||||
| 20 | Overall Size | 4500×800×1300mm | |||||
| 21 | Total Weight | 2T | |||||
Packaging & Shipping
5.Company Information
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
Our sales network covers all over China and all over the World.
Our excellent and professional after-sales team will supply perfect services. We have a detailed manual book and can supply you with technical support via phone and network. If necessary, we can supply you with local technical support and send technicians to for installation and operation training.
Our Company
5.FAQ
1:How to play order: Inquiry—confirm the profile drawings and price—-confirm the PI—arrange the deposit or L/C—then OK
2:How to visit our company:
Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can pick up you.
Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours),then we can pick up you.
3:When we exported the machines:
We have beening making and exporting the machines since from the year of 1998.
4:If you want to get more pictures or videos of the machines,I can send them to you by Email or SKype.
