Audsun Commerial Air Source Heat Pump Specification
Model Number ARG-03S ARG-05S ARG-07 ARG-10S ARG-15S ARG-20S
Referigerant   R417a / R22
Compressor Brand Copeland
Testing Condition 1. Dry-bulb temperature 20℃
2. Wet-bulb temperature 15℃
3. Water temp. rises 40 C deg.
Features 1. Environment Temp. for Working: -5°C to 40 °C
2. Max. Water Outlet Temp.: 60°C
Outdoor Unit Air Outlet Top Discharge Air Outlet
Rated Heat Production Capacity KW 10 16 22 32 48 65
BTU/h 34000 54400 74800 110000 163200 221000
Rated Outlet Water Temp. ℃ 55
Max. Outlet Water Temp. ℃ 60
Rated Water Heating Capacity L/h 210 350 460 700 920 1500
Rated Input KW 2.55 4.28 5.8 8.55 13 17
Rated Working Current A 12.7 7.5 11 15 22 29
COP W/W 3.8 3.8 3.8 3.8 3.8 3.8
Power Supply V/PH/HZ 220~240V/1PH/50HZ 380~415V/3PH/50HZ
Compressor QTY Unit 1 1 1 2 2 2
Fan QTY Unit 1 1 1 2 2 2
Sound Level dB(a) 65 65 65 68 68 68
Water Inlet/Outlet Diameter Inch G¾” G1″ G1″ G1½” G1½” G2½”
Water Inlet/Outlet Direction External Circulation Pump(Optional)
Circularation Pump Copper Pipe In Steel Case Heat Exchanger
Outline Dimension L×W×H(mm) 695×690×745 760×700×950 810×810×1350 1450×750×1100 1450×845×1370 1800×1100×1920
Packing Dimension L×W×H(mm) 760×755×915 830×770×1100 880×880×1550 1580×890×1300 1530×920×1570 1900×1160×2100
Net Weight KG 100 130 160 260 400 520
Gross Weight KG 115 160 190 300 460 600
