Automatic Case Erector
Inquire NowDescription
The Automatic Case Erector is a revolutionary machine designed for efficiency in packaging operations. This advanced equipment automatically performs the processes of carton erecting, rectangle forming, bottom flaps folding, and tape sealing, streamlining the workflow and reducing manual labor. It utilizes a vacuum sucker for opening cartons, ensuring precision and speed. Equipped with an alarm function, it alerts operators of any adhesive tape or carton shortages, preventing interruptions in production. The machine is easily adjustable, making it suitable for various carton sizes, enhancing versatility in packaging.
Specifications
| Model | CXJ-4030C |
|---|---|
| Voltage (V/Hz) | AC 380/50 220/60 3 phase |
| Power (W) | 800 |
| Air supply pressure (Kpa) | 0.5-0.6 |
| Capacity (case/min.) | ≤10 |
| Case dimensions (mm) | A: Min. 250 / Max. 400, B: Min. 150 / Max. 300, C: Min. 150 / Max. 300, D: Min. 400 / Max. 700, E: Min. 230 / Max. 500, F: Min. 300 / Max. 600 |
| Height of vacuum device (mm) | 700+(0-30) |
| Applicable tape type | BOPP, PVC, Kraft adhesive tape |
| Applicable tape size (mm) | Tape roll dia. ≤350, tape width 48 or 60 (standard) or 76 |
| External size (L×W×H)(mm) | 2300×2300×1850 |
| Weight (kg) | 500 |
| Note: The dimension A and B must be different. | |
Additional Information
For optimal performance, ensure the machine is regularly maintained and calibrated according to the manufacturer’s guidelines. Proper handling of adhesive tapes is essential for smooth operation.
