automatic reclosing leakage protector rccb
Inquire Now
Can work with circuit breakers and earth leakage switches, remote Closing and Sectional Breaker / Leakage Protection Switch
Controlling circuit breakers and leakage protection switches with switches，D type has auto-reclosing function
With manual and automatic switch
With mechanical and electronic, double lock function
Can work with auxiliaries
Work status is indicated by LED light
Operating mechanism only 18mm width
* Product Briefing
Function
-
Can work with circuit breakers and earth leakage switches, remote Closing and Sectional Breaker / Leakage Protection Switch
-
Controlling circuit breakers and leakage protection switches with switches，D type has auto-reclosing function
-
With manual and automatic switch
-
With mechanical and electronic, double lock function
-
Can work with auxiliaries
-
Work status is indicated by LED light
-
Operating mechanism only 18mm width
Technical Parameter
|
Model type |
|
EBS2LST |
|
Control method |
|
Digital input control and automatic recloser |
|
Power terminals |
|
A1-A2 |
|
Voltage fluctuation range |
|
AC 220V (50-60Hz) |
|
Power consumption |
|
AC max.1VA(standby) max. 20VA(Working) |
|
Indicator light |
|
Red and green LED |
|
Action time |
|
≤0.1S |
|
Automatic tripping times |
|
3 times |
|
Reclose time delay |
|
10S-60S-300S |
|
Clearing times after closing |
|
No more trips or clears within 15 minutes of successful closing |
|
Mechanical life |
|
10000 |
|
Electrical life |
|
4000 |
|
Working temperature |
|
-20℃ to +50℃(-4°F to 131°F) |
|
Installation |
|
Din rail EN/IEC60715 |
|
Protection class |
|
IP20 |
