AY single two-stage centrifugal oil pump
Inquire NowDescription
The AY single two-stage centrifugal oil pump is specifically designed for transporting petroleum, LPG, and other media devoid of solid particles, making it ideal for applications in petroleum refining, petrochemical, and chemical industries. With a remarkable traffic capacity ranging from 2.5 to 600 m³/h and a lift capability between 30 to 330 meters, this pump operates efficiently across a temperature range of 45 to 420 ℃. The AY series has been meticulously engineered to meet modern energy conservation requirements while ensuring reliability and performance.
This advanced pump is a modification of the older Y series, featuring enhanced hydraulic models that yield 5-8% greater efficiency. The structure and installation dimensions have been preserved for compatibility with existing systems, allowing for straightforward upgrades. Key characteristics include high part universalization, robust material selection for durability, and various cooling options tailored to specific operational temperatures.
Specifications
| Attribute | Details |
|---|---|
| Traffic Capacity | 2.5 ~ 600 m³/h |
| Lift | 30 ~ 330 m |
| Temperature Range | 45 ~ 420 ℃ |
| Model Specification | 50 ay Ⅱ 60 x 2 b, 250 ays Ⅲ 150 c |
| Suction Inlet Diameter | 50, 250 mm |
| Impeller Type | Double suction |
| Materials | HT250, ZG230-450, ZGCr13Ni |
Additional Information
The AY pump series incorporates a flexible diaphragm type lengthened coupling for easy maintenance, allowing for the removal of essential components without disassembling the suction or discharge pipelines. It also features various cooling methods, including air cooling, fan cooling, and water cooling, to cater to different operating conditions.
