BAIFA-KUBOTA series lighting tower

Inquire Now

BAIFA-KUBOTA series lighting tower

  • MODEL
VTH9 G4000 VTH9 G6000 VTH9 E1400 VTH9 E2000
Dimensions
Length 3400mm (11′ 2″ ) 3400mm (11′ 2″ ) 3400mm (11′ 2″ ) 3400mm (11′ 2″ )
Length for loading 2285mm (7′ 5 ½” ) 2285mm (7′ 5 ½” ) 2285mm (7′ 5 ½” ) 2285mm (7′ 5 ½” )
Width 1430mm ( 4′ 9″ ) 1430mm ( 4′ 9″ ) 1430mm ( 4′ 9″ ) 1430mm ( 4′ 9″ )
Height 2520mm ( 8′ 3″ ) 2520mm ( 8′ 3″ ) 2520mm ( 8′ 3″ ) 2520mm ( 8′ 3″ )
Height extended fully 8.7m (28′ 7″ ) 8.7m (28′ 7″ ) 8.7m ( 28′ 7″ ) 8.7m ( 28′ 7″ )
Gross weight 1280 kg ( 2800 lb ) 1450 kg ( 3200 lb ) 1230kg(2600 lb) 1250kg(2640 lb)
Engine
Model D1105 Kubota D1105 Kubota Z482 Kubota Z482 Kubota
Speed(rpm) 1500/1800 1500/1800 1500/1800 1500/1800
Engine characters 3 cylinders, 4 cycles & Water cooling 3 cylinders, 4 cycles & Water cooling 2 cylinders, 4 cycles & Water cooling 2 cylinders, 4 cycles & Water cooling
Combustion Direct injection Direct injection Direct injection Direct injection
Aspiration Naturally aspirated Naturally aspirated Naturally aspirated Naturally aspirated
Alternator
Model LT3N-130/4 Mecc alte LT3N-160/4 Mecc alte LT3N-75/4 Mecc alte LT3N-75/4 Mecc alte
Frequency (HZ) 50 60 50 60 50 60 50 60
Rating voltage 230 VAC 240/120 VAC 230 VAC 240/120 VAC 230 VAC 240/120 VAC 230 VAC 240/120 VAC
Insulation & Protection Class H & IP23 Class H & IP23 Class H & IP23 Class H & IP23
Mast & Lights
Light 4*1000W MH 4*1500W MH (Rectangle & Duble-end) 4*350W LED 4*500W LED
Luminous flux 110000 Lm/Light 140000 Lm/Light 52500 Lm/Light 75000 Lm/Light
Mast sections 6 6 6 6
Mast extension Hydraulic Hydraulic Hydraulic Hydraulic
Mast rotation Manual rotation with self-locking Manual rotation with self-locking Manual rotation with self-locking Manual rotation with self-locking
Light tilt Electric Electric Electric Electric
Trailer
Suspension & brake leaf-spring axle without brake leaf-spring axle without brake leaf-spring axle without brake leaf-spring axle without brake
Tow bar A style frame with a supporting wheel A style frame with a supporting wheel A style frame with a supporting wheel A style frame with a supporting wheel
Stabilizing leg 4 extendable bars with jacks 4 extendable bars with jacks 4 extendable bars with jacks 4 extendable bars with jacks
Wheel 14″ rim with regular tire 14″ rim with regular tire 14″ rim with regular tire 14″ rim with regular tire
Tow Coupler 2″ ball coupler or 3″ pintle ring 2″ ball coupler or 3″ pintle ring 2″ ball coupler or 3″ pintle ring 2″ ball coupler or 3″ pintle ring
Tail lights Complex tail lights Complex tail lights Complex tail lights Complex tail lights
Max towing speed 100km/h ( 62 mph) 100km/h ( 62 mph) 100km/h ( 62 mph) 100km/h ( 62 mph)
Other Features
Fuel tank 115 liters ( 30 US gal) bunded metal tank 115 liters ( 30 US gal) bunded metal tank 115 liters ( 30 US gal) bunded metal tank 115 liters ( 30 US gal) bunded metal tank
Operating hours 82 hours 55 hours 234 136
Control system Smartgen 404 Smartgen 404
