Description
The Steel Roof & Wall Forming Machine is engineered for efficiency and ease of use, featuring a remote control system that enhances operational convenience. Designed for the production of high-quality corrugated panels, this machine is suitable for various construction projects. Its robust construction ensures durability, while the lifetime video online service offers continuous support for users. With a maximum forming speed of 10-15 meters per minute, this machine excels in productivity, making it a valuable addition to any manufacturing line.
Specifications
| Parameter | Details |
|---|---|
| Material | Pre-painted & galvanized steel coil |
| Thickness (mm) | 0.3-0.7 |
| Tield stress (Mpa) | Q235-345 |
| Max. forming speed (m/min) | 10-15 |
| Roller material | #45 steel with hard chrome treatment |
| Roller driven type | Chain transmission |
| Controller | PLC |
| Operation | Touch screen and button |
| Hydraulic system pressure (Mpa) | 12 |
| Main motor power (KW) | 4 |
| Hydraulic station motor power | 3 |
| Dimension (L*W*H) | about 8500*1500*1500mm |
| Weight (KG) | about 6000 |
Additional Information
Our Service:
– Provide Pre-sales Consultant & On-purchase service & After-sales service 24hr × 7days per week
– Give technical suggestion
– Test the machine before shipment
– Provide technical guidance related to using the machine
– Supply one-year warranty period for the machine
– Provide spare parts at cost price after warranty period
– Collect feedback for machine performance
– Provide long-term technical assistance.
