best wall steel roof tile make machine
Inquire NowDescription
Introducing the advanced Steel Roof Tile Forming Machine, designed for efficiency and ease of use in the roofing industry. This innovative machine features a user-friendly remote control system and offers lifetime video online service for seamless operation. Crafted for high performance, it efficiently produces high-quality steel roof tiles with precision.
Specifications
| Product Name | Steel roof tile forming machine |
|---|---|
| Material | Pre-painted & galvanized steel coil |
| Thickness (mm) | 0.3-0.6mm |
| Tield Stress (Mpa) | Q235-345 |
| Max. Forming Speed (m/min) | 2-3; 5-6 |
| Roller Material | #45 steel with hard chrome treatment |
| Roller Driven Type | Chain transmission |
| Controller | PLC |
| Operation | Touch screen and button |
| Hydraulic System Pressure (Mpa) | 12 |
| Main Motor Power (KW) | 5.5 |
| Hydraulic Station Motor Power | 5.5 |
| Dimension (L*W*H) | about 8000*1500*1500mm |
| Weight (KG) | about 8000 |
Additional Information
Our Service:
- Provide Pre-sales Consultant & On-purchase service & After-sales service 24hr × 7days per week
- Give technical suggestions
- Test the machine before shipment
- Provide technical guidance related to using the machine
- Supply one-year warranty period for the machine
- Provide spare parts at cost price after the warranty period
- Collect feedback for the machine’s performance
- Provide long-term technical assistance
