Boom Topping Spreader CBTS-200
Inquire NowBoom Topping Spreader CBTS-200
Boom Topping Spreader CBTS-200
Disperse a wide variety of shake-on toppings with the Boom Topping Spreader. It’s uniquely versatile design features a low dust loading technology with Inlet Hopper brushes, storage for up to twenty 50-1 b. / 22.7 kg bags, and a compact machine size for easier transporting. CBTS-200 Topping Spreader provides spreading accuracy that allows you to distribute shake-on toppings from fine materials to trap rock.
Features：
Superior spreading accuracy
20ft (6 meter) boom reach
Easy-Loading
Improved operator visibility
Easy to maintain and service
Technical Specification：
| Model | CBTS-200 |
|
Engine Type: |
KUBOTA V1505-T Turbo Diesel |
|
Power kw(hp): |
32.5/44 |
|
Weight(kg): |
4020 |
|
Oil Tank Capacity L |
50 |
|
Hydraulic Oil Tank Capacity(L): |
75 |
|
Travelling speed (km/h): |
0-5 |
|
Spread head Width (mm): |
1820 |
|
Boom Arm System: |
Button proportional switch control, infinitely variable speeds |
|
Main pump: |
US Sauer-Danfoss axial piston pump |
|
Master valve: |
US Hydra Force main control valve |
|
Hydraulic hose: |
American GATES High pressure hoses |
