Brand new Weichai 80kw/100kva diesel generator water cooled open type/silence type generat
Inquire NowDescription
The Weichai 80kw/100kva diesel generator is designed for reliability and efficiency, making it an ideal solution for various power needs. This generator features a brand-new engine with a CE certificate, ensuring compliance with international safety standards. Its robust construction includes a heavy-duty steel base frame and a water-cooled system, available in both open and silent types, providing versatility for different operational environments.
Equipped with a brushless alternator, the generator operates smoothly and efficiently, while its H insulation class guarantees long-lasting performance under various conditions. The unit’s advanced design incorporates a vibration damper between the engine and alternator, enhancing stability during operation. Additionally, it comes with an industrial silencer that minimizes noise, making it suitable for residential and commercial use.
This generator offers a range of features, including an electric start with a 24V charger, an average 8-hour fuel tank, and standard tool kits along with complete operation and maintenance manuals for user convenience. Moreover, optional accessories enhance functionality, including automatic transfer switches, water heaters, and various sensors.
Specifications
| NO. | Genset model | Standby power (KVA) | Rated voltage | Rated current | Engine model | Max output (kw) | Speed (r/min) | Starting method | L*W*H (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 1 | HRC-20CF | 27.5 | 400 | 36 | ZH4100D | 33 | 1500 | 12V | 1800*840*1250 |
| 2 | HRC-24CF | 33 | 400 | 43.2 | ZH4100D | 33 | 1500 | 12V | 1800*840*1250 |
| 3 | HRC-30CF | 41.25 | 400 | 54 | ZH4100ZD | 45 | 1500 | 12V | 1800*840*1280 |
| 4 | HRC-40CF | 55 | 400 | 72 | R4105ID | 50.6 | 1500 | 12V | 1850*750*1350 |
| 5 | HRC-50CF | 68.75 | 400 | 90 | R4105ZD | 61.6 | 1500 | 24V | 1850*750*1350 |
| 6 | HRC-64CF | 88 | 400 | 115.2 | R6105ZD | 92.4 | 1500 | 24V | 2480*750*1360 |
| 7 | HRC-75CF | 103.125 | 400 | 135 | R6105ZD | 92.4 | 1500 | 24V | 2480*750*1360 |
| 8 | HRC-90CF | 123.75 | 400 | 162 | 6105AZLD | 121 | 1500 | 24V | 2480*750*1430 |
| 9 | HRC-100CF | 137.5 | 400 | 180 | 6105AZLD | 121 | 1500 | 24V | 2480*750*1430 |
| 10 | HRC-120CF | 165 | 400 | 216 | 6105IZLD | 145 | 1500 | 24V | 2480*750*1430 |
| 11 | HRC-150CF | 206.25 | 400 | 270 | HD6126ZLD11 | 187 | 1500 | 24V | 3150*1050*1650 |
| 12 | HRC-180CF | 247.5 | 400 | 324 | HD6126ZLD12 | 225 | 1500 | 24V | 3150*1050*1650 |
| 13 | HRC-200CF | 275 | 400 | 360 | HD6126ZLD | 247 | 1500 | 24V | 3150*1050*1650 |
Additional Information
- Standard tool kits and complete operation/maintenance manuals are included.
- Various optional features available to enhance functionality:
- Automatic Transfer Switch
- ABB and Schneider Breakers
- Water Heater
- Lub-oil Heater
- Fuel level sensor
- Low coolant level sensor
- External Daily Fuel Tank
- Water-Fuel Separator
- Controller options: Deepsea, DEIF, ComAP, and Woodward
