BTP BATHTUB PUMP
Inquire NowDescription
The BTP Bathtub Pump is a reliable single-stage centrifugal pump designed to efficiently manage water drainage. Ideal for residential and commercial settings, this pump is equipped with a complete drainage device to ensure optimal performance. Its robust construction features suction and discharge mountings made from durable polypropylene, complemented by a motor shaft crafted from stainless steel AISI 420 for enhanced longevity. The impeller is made from PPO, ensuring effective water flow, while the mechanical seal combines graphite and ceramic for superior sealing capabilities. The motor housing is constructed from lightweight aluminum, making installation and maintenance straightforward.
This asynchronous motor operates at two poles with IP55 protection, making it resistant to dust and water ingress. With class F insulation, it guarantees high operational efficiency and safety. The pump operates continuously and features a single-phase version with built-in thermal protection, providing peace of mind during use.
Specifications
| Attribute | Details |
|---|---|
| Type | Single-stage centrifugal pump |
| Material | Suction and discharge mountings: Polypropylene, Motor shaft: S/S AISI 420, Impeller: PPO, Mechanical seal: Graphite and ceramic, Motor housing: Aluminum |
| Motor Type | Asynchronous, two poles |
| Protection Rating | IP55 |
| Insulation Class | Class F |
| Operation | Continuous |
| Thermal Protection | Built-in for single phase version |
