C Purlins Steel Purlin Cold Roll Forming Machine price
Inquire NowDescription
The Steel Purlin Cold Roll Forming Machine is a state-of-the-art solution designed for the efficient production of C, Z, and U shape steel purlins. This machine is not only easy to operate with its intuitive remote control but also offers a lifetime of video online service for troubleshooting and guidance. With a robust construction and high-speed performance, it meets the demands of modern manufacturing while ensuring sustainability and precision in steel forming.
Specifications
| Product Name | Steel purlin roll forming machine |
|---|---|
| Profile | C shape, Z shape, U shape |
| Material Type | Galvanized steel coil |
| Thickness (mm) | 1.5-3.0mm |
| Tield stress (Mpa) | Q235-345 |
| Max. forming speed (m/min) | 10-15 m/min |
| Roller material | Bearing steel GCr15 |
| Roller driven type | Chain transmission |
| Controller | PLC |
| Operation | Touch screen and button |
| Hydraulic system pressure (Mpa) | 20 |
| Main motor power (KW) | 18.5-22 |
| Hydraulic station motor power | 5.5 |
| Dimension (L*W*H) | about 10000*1000*1500mm |
| Weight (KG) | about 10000 |
Additional Information
Our Service:
– Provide Pre-sales Consultant & On-purchase service & After-sales service 24hr × 7 days per week
– Give technical suggestions
– Test the machine before shipment
– Provide technical guidance related to using the machine
– Supply one-year warranty period for the machine
– Provide spare parts at cost price after warranty period
– Collect feedback for the machine working
– Provide long-term technical assistance.
Images
