Description
The CDB2-F15 Sectional Multiple Directional Control Valve is an essential component for hydraulic systems, designed to provide precise control over fluid flow and direction. This high-performance valve features a nominal diameter of 15mm, making it suitable for a wide range of applications in industrial and mobile machinery. With a nominal pressure rating of 200 bar and a maximum pressure capability of 280 bar, the CDB2-F15 is engineered to handle demanding conditions and ensure reliable operation.
Designed for efficiency, this valve offers a nominal flow rate of 63 L/min, with the capacity to handle maximum flow rates of up to 80 L/min. Its robust construction and advanced features make it an ideal choice for users seeking durability and performance in their hydraulic systems.
Specifications
| Feature | Specification |
|---|---|
| Nominal Diameter | 15 mm |
| Nominal Pressure | 200 bar |
| Maximum Pressure | 280 bar |
| Nominal Flow Rate | 63 L/min |
| Maximum Flow | 80 L/min |
