Ceramic tile inkjet printer D1170-10 (fast version)

Products Characters

• Max printing systems carries 16 levels grey scales processing capabilities which can meet the requirements of delicacy and balance

• Balanced and optimized printing control board installed in individual printhead is equipped with independent CPU with exclusive 4G memory

• Compensation function for injectors blockage can avoid the product quality problem of line defect

• Whole inkjet printer structure is fully optimized with environmental protection and advanced HMI evolution

• The stability of the high-flow internal ink circulation system is 35% higher than the previous one

• Ink circulation is closed-loop control fully for flow rate balance which meets for both light or dark colors production needs

• The ink circulation is equipped with water bath heating in order to support high-flow printing per glaze effect inks

• High ink flow circulation in 130ml/per min is more suitable for ceramic ink inkjet printing

• Optional 4 types of drive waveforms selectable: fine, standard, high volume, and super high ink volume 108mm printing width per each single printhead

• Smallest ink drop is 13pl which can show the delicate inkjet printing resolution

• Maximum big ink drop is 133pl which is a powerful tool for dark design tile production

• MAX RC1356 L / RCH 1536L glaze effect inks / Cover inks higher than 45g/sqm (Density 1300g/cm³ )

  Inkjet printer parameters(D1170-10 accelerated version)
  Size	5940mm x 2280mm x 2150mm( L x W x H)
  Capacity	15KW
  Weight	4.5T
  Printhead N° supported	Magic cube
  Inkjet printing grey scales	16 levels
  Ink circulation mode	Printhead internal circulation+Ink circulation unity
  Ink circulation q’ty	130ml/min
  Inkjet printing resolution	360dpi
  Inkjet printing volume	35g/㎡ / 85g/㎡(Big volume inkjetting printhead)
  Inkjet printing printhead board	Upgrade 4G printhead board
  Inkjet printing system	Independent R&D system under Windows system+Multi Gigabit network upload
  Inkjet printing size	1170mm
  N° of channels	10 channels
  Unique technology of image processing	Compensation function for joints, 2-ways color di?erence or injectors blockage
  Requirements for ceramic inkjet printer goes into production
  Envirorment temperature	23~28℃
  Environment humidity	60%~75%
  Requirements for ground wire	Reliable and independent ground connection
  Tile biscuits’ temperature	30~38℃
  Ink storage temperature	and without direct sunlight exposure
  Dust control	No dust found on tile biscuits, Keep the inkjet room dean and dustless
  Requirement for power supply	380V (3F+N+GND) 50/60Hz
