China 30kw single phase diesel generator water cooled with Smartgen Auto control system
Inquire NowDescription
The China 30kw single-phase diesel generator is a robust and efficient power solution designed for various applications. Engineered with a state-of-the-art Smartgen Auto control system, this generator ensures reliable performance and ease of use. It features a brand-new, CE-certified engine paired with a brushless alternator, ensuring durability and low maintenance. The heavy-duty steel base frame provides stability, while the advanced water cooling system ensures optimal performance even in demanding conditions.
Key features include an industrial silencer for noise reduction, vibration dampers to minimize operational disturbances, and comprehensive filter systems including air, oil, and fuel filters. The generator is equipped with a battery for electric start and can support a fuel tank that provides an average of 8 hours of operation. With optional add-ons such as an Automatic Transfer Switch and various sensor upgrades, this generator can be tailored to meet specific needs.
Specifications
| NO. | Genset model | Standby power (KVA) | Rated voltage | Rated currency | Engine model | Max output (kw) | Speed (r/min) | Starting method | L*W*H(mm) |
|---|---|---|---|---|---|---|---|---|---|
| 1 | HRC-20CF | 27.5 | 400 | 36 | ZH4100D | 33 | 1500 | 12V | 1800*840*1250 |
| 2 | HRC-24CF | 33 | 400 | 43.2 | ZH4100D | 33 | 1500 | 12V | 1800*840*1250 |
| 3 | HRC-30CF | 41.25 | 400 | 54 | ZH4100ZD | 45 | 1500 | 12V | 1800*840*1280 |
| 4 | HRC-40CF | 55 | 400 | 72 | R4105ID | 50.6 | 1500 | 12V | 1850*750*1350 |
| 5 | HRC-50CF | 68.75 | 400 | 90 | R4105ZD | 61.6 | 1500 | 24V | 1850*750*1350 |
| 6 | HRC-64CF | 88 | 400 | 115.2 | R6105ZD | 92.4 | 1500 | 24V | 2480*750*1360 |
| 7 | HRC-75CF | 103.125 | 400 | 135 | R6105ZD | 92.4 | 1500 | 24V | 2480*750*1360 |
| 8 | HRC-90CF | 123.75 | 400 | 162 | 6105AZLD | 121 | 1500 | 24V | 2480*750*1430 |
| 9 | HRC-100CF | 137.5 | 400 | 180 | 6105AZLD | 121 | 1500 | 24V | 2480*750*1430 |
| 10 | HRC-120CF | 165 | 400 | 216 | 6105IZLD | 145 | 1500 | 24V | 2480*750*1430 |
| 11 | HRC-150CF | 206.25 | 400 | 270 | HD6126ZLD11 | 187 | 1500 | 24V | 3150*1050*1650 |
| 12 | HRC-180CF | 247.5 | 400 | 324 | HD6126ZLD12 | 225 | 1500 | 24V | 3150*1050*1650 |
| 13 | HRC-200CF | 275 | 400 | 360 | HD6126ZLD | 247 | 1500 | 24V | 3150*1050*1650 |
Additional Information
- Standard tool kits and complete operation/maintenance manuals included.
- Option for additional features such as a fuel level sensor, low coolant level sensor, and external daily fuel tank.
- Controller options available: Deepsea, DEIF, ComAP, and Woodward.
