Description
The China Diesel Engine 150hp R6105 series is a robust and innovative power solution designed for efficiency and durability. With a newly compact design, this engine ensures ease of installation and transport, making it ideal for a range of applications. It boasts leading indicators in mean effective pressure and power, setting a standard in the industry.
Key features include enhanced water filtration systems that cleanse fuel, safeguarding the injector and high-pressure pump, thereby extending the engine’s lifespan. The specialized piston ring sealing and valve sealing techniques significantly reduce fuel consumption, while high-pressure forged components improve fatigue strength and wear resistance. With an overhaul interval exceeding 10,000 hours, this engine is built for long-term performance and reliability.
Specifications
| Model | Type | Aspiration | Displacement (Liter) | Bore*Stroke (mm) | KW@1500rpm | KW@1800rpm | Dimension (mm) | Net Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| K4100D | L 4 | NA | 3.61 | 100×115 | 30.1 | 36 | 950*660*950 | 330 |
| K4100ZD | L 4 | TC | 3.61 | 100×115 | 41.2 | 47 | 950*660*980 | 340 |
| K4102ZD | L 4 | TC | 3.76 | 102×115 | 45 | 50 | 950*660*980 | 360 |
| R4105ZD | L 4 | TC | 4.33 | 105×125 | 56 | 67 | 950*750*1080 | 435 |
| R6105ZD | L 6 | TC | 6.49 | 105×125 | 84 | 90 | 1190*750*1190 | 580 |
| R6105AZLD | L 6 | TI | 6.75 | 105×130 | 110 | 125 | 1280*780*1190 | 620 |
| R6105IZLD | L 6 | TI | 7.10 | 105×135 | 135 | 145 | 1280*780*1190 | 620 |
| HD6126ZLD | L 6 | TI | 9.726 | 126×130 | 235 | 235 | 2230*780*1539 | 950 |
| HD12ZLD | L 6 | TI | 11.596 | 126×155 | 288 | 301 | 2230*780*1539 | 1100 |
Additional Information
- Overhaul interval greater than 10,000 hours.
- Designed for ease of installation and transportation.
