China hot brand diesel generator 30kw four stroke multi-cylinder engine water cooled
Inquire NowDescription
The 30kW Diesel Generator is a robust and reliable power solution, equipped with a four-stroke multi-cylinder engine that is water-cooled for enhanced performance. This generator is ideal for various applications, providing consistent power where you need it most. Its newly designed brushless alternator ensures efficiency and durability, making it an excellent choice for both commercial and residential use.
Key features of this generator include a heavy-duty steel base frame that promotes stability and durability, a high-performance radiator adaptable to different environmental conditions, and effective vibration dampers to reduce noise and prolong engine life. The industrial silencer is also designed for optimal sound reduction, making this generator quieter during operation.
To maximize your generator’s performance and efficiency, it comes with essential filters, including air, oil, and fuel filters, alongside an electric start system and a 24V charger. The average fuel tank capacity allows for up to 8 hours of continuous operation, providing uninterrupted power supply for your needs.
Additionally, various optional features are available to customize your generator further, such as automatic transfer switches, advanced controller options, and extra filters to enhance maintenance and operation efficiency.
Specifications
| NO. | Genset Model | Standby Power (KVA) | Rated Voltage | Rated Currency | Engine Model | Max Output (kW) | Speed (r/min) | Starting Method | Exciting Method | L*W*H (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | HRC-20CF | 27.5 | 400 | 36 | ZH4100D | 33 | 1500 | 12V | Brushless | 1800*840*1250 |
| 2 | HRC-24CF | 33 | 400 | 43.2 | ZH4100D | 33 | 1500 | 12V | Brushless | 1800*840*1250 |
| 3 | HRC-30CF | 41.25 | 400 | 54 | ZH4100ZD | 45 | 1500 | 12V | Brushless | 1800*840*1280 |
| 4 | HRC-40CF | 55 | 400 | 72 | R4105ID | 50.6 | 1500 | 12V | Brushless | 1850*750*1350 |
| 5 | HRC-50CF | 68.75 | 400 | 90 | R4105ZD | 61.6 | 1500 | 24V | Brushless | 1850*750*1350 |
| 6 | HRC-64CF | 88 | 400 | 115.2 | R6105ZD | 92.4 | 1500 | 24V | Brushless | 2480*750*1360 |
| 7 | HRC-75CF | 103.125 | 400 | 135 | R6105ZD | 92.4 | 1500 | 24V | Brushless | 2480*750*1360 |
| 8 | HRC-90CF | 123.75 | 400 | 162 | 6105AZLD | 121 | 1500 | 24V | Brushless | 2480*750*1430 |
| 9 | HRC-100CF | 137.5 | 400 | 180 | 6105AZLD | 121 | 1500 | 24V | Brushless | 2480*750*1430 |
| 10 | HRC-120CF | 165 | 400 | 216 | 6105IZLD | 145 | 1500 | 24V | Brushless | 2480*750*1430 |
| 11 | HRC-150CF | 206.25 | 400 | 270 | HD6126ZLD11 | 187 | 1500 | 24V | Brushless | 3150*1050*1650 |
| 12 | HRC-180CF | 247.5 | 400 | 324 | HD6126ZLD12 | 225 | 1500 | 24V | Brushless | 3150*1050*1650 |
| 13 | HRC-200CF | 275 | 400 | 360 | HD6126ZLD | 247 | 1500 | 24V | Brushless | 3150*1050*1650 |
Additional Information
- Includes standard tool kits and complete operation/maintenance manuals for ease of use.
- Available options for enhanced functionality, including automatic transfer switches and extra fuel filters.
- Electric start for quick and convenient operation.
